The Hager W.1 2-way push-button 1O/1F, composable with light, delivers reliable momentary control for lighting and auxiliaries. Rated 10A, 250V, 50-60Hz, it features a double push-button, turn screw terminals, and flush or surface mounting. IP55 and IK08 ensure weatherproof, impact-resistant use indoors or outdoors. Polar white matt thermoplastic. Optional indicator lamp. Compatible with cubyko.
EAN
3250617175456
Packaging
1 Piece
Key switch 3-position momentary 10A IP55 IK08 flush/surface grey cubyko WNA045B
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Illumination insert for domestic switching devices 3 products available -
Cover frame for domestic switching devices 4 products available -
Surface-mounted housing for flush-mounted switching device 5 products available
Compatible products
-
Referenced by 23 products available
Complete your system
-
WNA685Bcubyko Double horizontal box empty with 4 sliders white IP55
-
WNA682Bcubyko Double horizontal box empty with 2 sliders white IP55
-
WNA681B
Surface-mounted lower casing 1gang with frame and cable entries W.1 polar white
-
WNA683BSurface-mounted lower casing 3gang horizontal, w. frame and cable entries W.1 pw
-
WNA686BSurface-mounted lower casing 2gang vertical, w. frame and cable entries W.1 pw
Referenced by
-
WNA683B
Surface-mounted lower casing 3gang horizontal, w. frame and cable entries W.1 pw
-
WNA694Connector for multiple combinations surface-mtd, W.1, grey matt
-
WNA408Frame 2gang vertical for flush-mounted installation, with sealing W.1 light grey
-
WNA402BFrame 2gang horizontal for flush-mounted installation, with sealing, W.1, p-w
-
WNA401B
Frame 1gang for flush-mounted installation, with sealing, W.1, polar white
-
WNA693Tube entry M20 x 1.5, boltable, W.1, grey matt
-
WNA691Cable + tube entry, W.1, grey matt
-
WNA691BCable + tube entry, W.1, p. white, matt, plastic
-
WNA690Cable entry for 2 cables, W.1, grey matt
-
WNA690BCable entry for 2 cables, W.1, p. white, matt, plastic
-
WNA686B
Surface-mounted lower casing 2gang vertical, w. frame and cable entries W.1 pw
-
WNA683Surface-mounted lower casing 3gang hor., w. frame and cable entries W.1 grey
-
WNA682cubyko Double horizontal box empty with 2 sliders grey IP55
-
WNA684cubyko Single box empty with sliders for 1 cable grey IP55
-
WNA681B
Surface-mounted lower casing 1gang with frame and cable entries W.1 polar white
-
WNA682B
cubyko Double horizontal box empty with 2 sliders white IP55
-
WNA685B
cubyko Double horizontal box empty with 4 sliders white IP55
-
WNA685cubyko Double horizontal box empty with 4 sliders grey IP55
-
WNA408Bcubyko Double vertical flush adapter white IP55
-
WNA403Bcubyko Triple horizontal flush adapter white IP55
Technical properties
Electric current
-
Switching current10 A
-
Momentary contact current10 A
Voltage
-
Rated voltage250 V
Frequency
-
Frequency50 - 60 Hz
Architecture
-
Control/operation elementDouble rocker
Materials
-
ColourWhite
-
Surface finishMatt
-
MaterialThermoplastic
-
TreatmentUntreated
-
TransparentNo
-
Contains recycled material (% of total plastic weight)0
-
Backside internalMatt
Dimensions
-
Height75 mm
-
Width75 mm
-
Depth40 mm
-
Built-in depth12 mm
-
Built-in depth flush-mounted boxes0
Installation, mounting
-
Mounting onFlush mounting, Surface mounting
Controls and indicators
-
Indicator lampAs an accessory
-
Number of buttons2
-
Type of push buttonSeries push button
-
With feedback signal contactNo
Connectivity
-
With claw mountingNo
Connection
-
Connector/plug typeTurn screw lock
Safety
-
Ingress Protection (IP) classIP55
-
Impact resistance IKIK08
Accessories
-
Has labelling fieldNo
-
Related Systemscubyko
