125A 4 Way TPN Board with 4 pole SD & Type II SPD Glazed JK104BGSPD
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
-
Fixing modesurface-mounting
-
Frequency50 Hz
-
Depth of installed product132.5 mm
-
Height of installed product500 mm
-
Width of installed product465 mm
-
Type of door closingQuarter turn lock
-
InterlockableYes
-
ColourRAL 7035
-
RAL colourRAL 7035 - Light grey
-
MaterialSteel
-
Can be accessorizedYes
-
European directive WEEEconcerned
-
Protection index IPIP30
-
Protection classisol.class I
-
Operating temperature50…-10 °C
Downloads
-
Product image
-
Product notice
Instruction manuals for JK104BGSPD
Installation manual en-GB 2017-05-17
PDF1 MB -
BIM models
BIM models for JK104BGSPD
UK_INVICTA_BIM_TPN125A
ZIP1 MB -
Product datasheet
Product data sheets for JK104BGSPD
UK_CD_TDS_PrimaryBoardSideDINboxes.pdf
PDF104 KBProduct data sheets for JK104BGSPD
UK_CD_TDS_TPN125-250characteristics.pdf
PDF55 KB -
Product declaration
EU Declaration of conformity for JK104BGSPD
PDF163 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF223 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF190 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF154 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF216 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF217 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF174 KBEU Declaration of conformity for JK104BGSPD
Declaration
PDF222 KBEU Declaration of conformity for JK104BGSPD
PDF253 KBEU Declaration of conformity for JK104BGSPD
PDF158 KBEU Declaration of conformity for JK104BGSPD
PDF247 KBEU Declaration of conformity for JK104BGSPD
PDF226 KBEU Declaration of conformity for JK104BGSPD
PDF219 KB -
Product ROHS
Pollutant guidelines for JK104BGSPD
REACH-declaration 2023-10-20 (english)
PDF33 KB
