JK106BGSPD

125A 6 Way TPN Board with 4 pole SD & Type II SPD Glazed
EAN
5015652603405
Quantity
1
Trade price*
£868.04 /prt.*
  • Architecture
    • Fixing mode
      • surface-mounting
  • Main electrical features
    • Frequency
      • 50 Hz
    • Rated current
      • 125 A
  • Dimensions
    • Depth of installed product
      • 132.5 mm
    • Height of installed product
      • 550 mm
    • Width of installed product
      • 465 mm
  • Capacity
    • Number of modules
      • 18
  • Cover, door
    • Type of door closing
      • Quarter turn lock
    • Interlockable
      • Yes
  • Materials
    • Colour
      • RAL 7035
    • RAL colour number
      • 7035
    • Material
      • Steel
  • Equipment
    • Can be accessorized
      • Yes
  • Standards
    • European directive WEEE
      • concerned
  • Safety
    • Protection index IP
      • IP30
    • Protection class
      • isol.class I
  • Use conditions
    • Operating temperature
      • 50…-10 °C
Documentations
Product data sheets for JK106BGSPD 104 KBPDFDownload
Product data sheets for JK106BGSPD 307 KBPDFDownload
Product data sheets for JK106BGSPD 55 KBPDFDownload
Instruction manuals for JK106BGSPD 1 MBPDFDownload
Commercial Distribution Catalogue 13 MBPDFDownload
More documentation
Tools and software
BIM models for JK106BGSPD 1 MB ZIPDownload
More Tools and software
