sock.outl. insert w. earth.pin a. hing. cov. SM/flush-mounted, cont.prot., W.1 WNA105

EAN
3250617174053
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

sock.outl. insert w. earth.pin a. hing. cov. SM/flush-mounted, cont.prot., W.1

WNA105

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products

Complete your system

Optional accessories

  • Surface-­mounted housing for flush-­mounted switching device 4 products available

Compatible products

  • Referenced by 19 products available

Complete your system

  • Surface-­mounted housing for flush-­mounted switching device
  • WNA686

    cubyko Double vertical box empty grey IP55
    0.00 €  / *
  • WNA685

    cubyko Double horizontal box empty with 4 sliders grey IP55
    0.00 €  / *
  • WNA682

    cubyko Double horizontal box empty with 2 sliders grey IP55
    0.00 €  / *
  • WNA683

    cubyko Triple horizontal box empty grey IP55
    0.00 €  / *

Referenced by

  • WNA408B

    cubyko Double vertical flush adapter white IP55
    0.00 €  / *
  • WNA681B

    Surface-mounted lower casing 1gang with frame and cable entries W.1 polar white
    0.00 €  / *
  • WNA402B

    cubyko Double horizontal flush adapter white IP55
    0.00 €  / *
  • WNA682B

    cubyko Double horizontal box empty with 2 sliders white IP55
    0.00 €  / *
  • WNA683B

    cubyko Triple horizontal box empty white IP55
    0.00 €  / *
  • WNA683

    cubyko Triple horizontal box empty grey IP55
    0.00 €  / *
  • WNA403B

    cubyko Triple horizontal flush adapter white IP55
    0.00 €  / *
  • WNA401

    cubyko Single flush adapter composable grey IP55
    0.00 €  / *
  • WNA403

    cubyko Triple horizontal flush adapter grey IP55
    0.00 €  / *
  • WNA686B

    cubyko Double vertical box empty white IP55
    0.00 €  / *
  • WNA401B

    cubyko Single flush adapter composable white IP55
    0.00 €  / *
  • WNA408

    cubyko Double vertical flush adapter grey IP55
    0.00 €  / *
  • WNA403

    cubyko Triple horizontal flush adapter grey IP55
    0.00 €  / *
  • WNA402

    cubyko Double horizontal flush adapter grey IP55
    0.00 €  / *
  • WNA682

    cubyko Double horizontal box empty with 2 sliders grey IP55
    0.00 €  / *
  • WNA685

    cubyko Double horizontal box empty with 4 sliders grey IP55
    0.00 €  / *
  • WNA685B

    cubyko Double horizontal box empty with 4 sliders white IP55
    0.00 €  / *
  • WNA686

    cubyko Double vertical box empty grey IP55
    0.00 €  / *
  • WNA682

    cubyko Double horizontal box empty with 2 sliders grey IP55
    0.00 €  / *

Technical properties

Elec­tric current
  • Rated current
    16 A
Voltage
  • Nominal voltage
    250 - 250 V
Frequency
  • Frequency
    50 - 60 Hz
Mater­ials
  • Colour
    Grey
  • RAL code
    7011
  • Surface finish
    Matt
  • Material
    Polycar­bonate (PC), Polypro­pylene (PP)
  • Treat­ment
    Untreated
Dimen­sions
  • Height
    75 mm
  • Width
    75 mm
  • Depth
    22.80 mm
  • Number of units
    1
  • Built-in depth flush-­mounted boxes
    35 mm
Connec­tion
  • Connect­or/plug type
    Turn screw lock
Install­a­tion, mounting
  • Mounting on
    Flush mounting, Surface mounting
Connectivity
  • Type of connec­tion
    Plug-in connec­tion
  • Mounting type
    Screw mounting
Equip­ment
  • Connect­or/plug type socket outlet
    Earthing pin
  • Rotated central insert
    No
  • With hinged lid
    Yes
  • With round protective earth pin
    Yes
  • With signal lamp
    No
  • With lock
    No
Accessories
  • Has labelling field
    Yes
Cover, door
  • Type of lid
    Self-closing hinged cover, can be arrested in end posi­tion
Capa­city
  • Number of modules
    2
Safety
  • With enhanced contact protec­tion
    Yes
  • Impact resist­ance IK
    IK08
  • Ingress Protec­tion (IP) class
    IP55
Func­tions
  • With orient­a­tion lighting
    No
  • With func­tion lighting
    No
Iden­ti­fic­a­tion
  • With imprint
    No
  • Related Systems
    Hager cubyko

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
REACh-SVHC free Yes
