Moulded Case Circuit Breaker h3+ P160 TM ADJ 3P3D 100A 25kA CTC HHS100DC
Price
£412.70
/ piece
*
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
product.page.accessories.title
product.page.accessories.associated-products
-
Under voltage coil 8 product.page.accessories.products-available -
Locking interlocking functions 5 product.page.accessories.products-available -
Shunt release 5 product.page.accessories.products-available -
Connection Functions 5 product.page.accessories.products-available -
Auxiliaries contact block 4 product.page.accessories.products-available -
Terminal cover 6 product.page.accessories.products-available
product.page.accessories.title-modal
-
HXA051H
UVR delayed 24V DC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA014HUndervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)
£180.56 / piece* -
HXA055HUVR delayed 380-450V AC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA054HUVR delayed 220-240V AC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA011HUndervoltage release 24V DC (x160-P160-x250-P250-x630-P630)
£147.33 / piece* -
HXA053HUVR delayed 110-120V AC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA013HUndervoltage release 100-120V AC (x160-P160-x250-P250-x630-P630)
£159.13 / piece* -
HXA015HUndervoltage release 380-450V AC (x160-P160-x250-P250-x630-P630)
-
HXA039H
Padlock (x160-P160-x250-P250-x630)
£21.63 / piece* -
HXB070HInterlock mechanical cable 1.0m (P160-x250-h250-h400-h630-h800-h1000)
£101.39 / piece* -
HXB071HInterlock mechanical cable 1.5m (P160-x250-h250-h400-h630-h800-h1000)
£106.59 / piece* -
HXS066HMechanical interlocking front cover P160
£68.62 / piece* -
HXS165HDirect interlocking kit P160 3P
£54.90 / piece*
-
HXA003H
Shunt trip 100-120V AC (x160-P160-x250-P250-x630-P630)
£259.37 / piece* -
HXA005HShunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)
£194.96 / piece* -
HXA002HShunt trip 48V DC (x160-P160-x250-P250-x630-P630)
£143.78 / piece* -
HXA001HShunt trip 24V DC (x160-P160-x250-P250-x630-P630)
£149.69 / piece* -
HXA004HShunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)
£256.92 / piece*
-
HYS014HSpread terminal extension P160 3P cage version
£61.77 / piece* -
HYS131H
Rear connection for P160 3P (63-160A)
£65.20 / piece* -
HYS001HCage terminal P160 cage version Cu/Al 3P 1x 10-95mm²
£51.47 / piece* -
HYS005HCage terminal P160 cage version Al 3P 1x35-120mm²
£58.34 / piece* -
HYS328HL connection terminal Plug-in P160 1P
£30.89 / piece*
-
HXA026H
Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
£54.30 / piece* -
HXA021HAuxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
£115.78 / piece* -
HXA024HAlarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
£68.53 / piece* -
HXA025HAuxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
£199.08 / piece*
-
HYS321H
Terminal cover for Plug-in base P160 3P
£41.18 / piece* -
HYS021HTerminal cover for Straight terminal extension P160 3P
£40.79 / piece* -
HYS023HTerminal cover for Spread terminal extension P160 3P
£51.47 / piece* -
HYS025HTerminal cover for Rear & Plug-in connection P160 3P
£34.31 / piece* -
HYS050HEarth plate for Straight terminal extension P160 3P
£34.31 / piece* -
HYS052HEarth plate for Spread terminal extension P160 3P
£34.31 / piece*
-
HYS033HDIN Rail adaptator P160 3P/4P
£27.45 / piece*
-
HXS030HDirect rotary handle for P160
£82.35 / piece*
-
HXS031HRotary handle on door for P160
£197.13 / piece*
-
HXS032HDirect rotary handle P160 with interlocking
£144.11 / piece*
-
HYS019HInterphase barrier for P160 3/4P
£15.45 / piece*
-
HYS200HPlug-in base for P160 3P
£199.00 / piece* -
HYS300HPlug-in adaptor for P160 3P (63-160A)
£120.10 / piece*
-
HYS256HSafety trip (P160-P250)
£68.62 / piece*
Technical characteristics
Electric current
-
Rated current IN100 A
-
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-225 kA
-
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-235 kA
-
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-235 kA
-
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-225 kA
-
Rated ultimate short-circuit breaking capacity Icu under 660 V AC IEC 60947-26 kA
-
Rated ultimate short-circuit breaking capacity Icu under 690 V AC IEC 60947-26 kA
-
Rated current at 10°C according to IEC 60947124.30 A
-
Rated current at 15°C according to IEC 60947121.50 A
-
Rated current at 20°C according to IEC 60947118.70 A
-
Rated current at 25°C according to IEC 60947115.80 A
-
Rated current at 30°C according to IEC 60947112.80 A
-
Rated current at 35°C according to IEC 60947109.70 A
-
Rated current at 40°C according to IEC 60947106.60 A
-
Rated current at 45°C according to IEC 60947103.30 A
-
Rated current at 50°C according to IEC 60947100 A
-
Rated current at 55°C according to IEC 6094796.50 A
-
Rated current at 60°C according to IEC 6094793 A
-
Rated current at 65°C according to IEC 6094789.20 A
-
Rated current at 70°C according to IEC 6094785.30 A
Architecture
-
Number of poles3
-
Control/operation elementToggle
-
Device construction typeFixed built-in
-
Neutral positionWithout neutral
Frequency
-
Frequency50 - 60 Hz
Voltage
-
Rated impulse withstand voltage Uimp8,000 V
-
Rated insulation voltage Ui800 V
-
Rated operational voltage Ue220 - 690 V
Functions
-
Trip unitTM A/A
Power
-
Power dissipation at IN20.10 W
Endurance
-
Electric endurance in number of cycles10,000
-
Number of mechanical operations40,000
Safety
-
Ingress Protection (IP) classIP4X
Connection
-
Cross-section flexible conductor6 - 70 mm²
-
Cross-section rigid conductor6 - 95 mm²
Connectivity
-
Type of connectionScrew terminal
Cover, door
-
InterlockableYes
Settings
-
Thermal protection knob setting xIN0.63, 0.8, 1
Cable
-
Cable materialCopper
Compatibility
-
Compatible with RDC AOBNo
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Dimensions
-
Height130 mm
-
Width90 mm
-
Depth97 mm
Electrical protection
-
Instantaneous protection (li): dial setting coefficient6, 8, 10, 12
Installation, mounting
-
Mounting-/Connection PositionFront
-
Nominal tightening torque6 - 6 Nm
-
Nominal tightening torque down terminal6 - 6 Nm
-
Nominal tightening torque top terminal6 - 6 Nm
catalog.pageproduct.title_sustainability.h2
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
catalog.pageproduct.sustainability_block.downloads_h3
Downloads
-
Product image
-
GeneratedProductDatasheet
Hager Product data sheet HHS100DC
