Moulded Case Circuit Breaker h3+ P160 TM ADJ 3P3D 25A 25kA CTC HHS025DC
EAN-Nr.
3250613177904
Packaging
1 piece
Price
£390.86
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Terminal cover 6 products available -
Under voltage coil 8 products available -
Connection Functions 5 products available -
Shunt release 5 products available -
Locking interlocking functions 5 products available -
Auxiliaries contact block 4 products available
Complete your system
-
HYS321H
Terminal cover for Plug-in base P160 3P
£41.18 / piece* -
HYS021HTerminal cover for Straight terminal extension P160 3P
£40.79 / piece* -
HYS023HTerminal cover for Spread terminal extension P160 3P
£51.47 / piece* -
HYS025HTerminal cover for Rear & Plug-in connection P160 3P
£34.31 / piece* -
HYS050HEarth plate for Straight terminal extension P160 3P
£34.31 / piece* -
HYS052HEarth plate for Spread terminal extension P160 3P
£34.31 / piece*
-
HXA051H
UVR delayed 24V DC (x160-P160-x250-P250-x630-P630)
£643.52 / piece* -
HXA014HUndervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)
£171.96 / piece* -
HXA055HUVR delayed 380-450V AC (x160-P160-x250-P250-x630-P630)
£643.52 / piece* -
HXA054HUVR delayed 220-240V AC (x160-P160-x250-P250-x630-P630)
£643.52 / piece* -
HXA011HUndervoltage release 24V DC (x160-P160-x250-P250-x630-P630)
£140.31 / piece* -
HXA053HUVR delayed 110-120V AC (x160-P160-x250-P250-x630-P630)
£643.52 / piece* -
HXA013HUndervoltage release 100-120V AC (x160-P160-x250-P250-x630-P630)
£151.55 / piece* -
HXA015HUndervoltage release 380-450V AC (x160-P160-x250-P250-x630-P630)
-
HYS014HSpread terminal extension P160 3P cage version
£61.77 / piece* -
HYS031H
Rear connection for P160 3P (16-50A)
£56.63 / piece* -
HYS001HCage terminal P160 cage version Cu/Al 3P 1x 10-95mm²
£51.47 / piece* -
HYS005HCage terminal P160 cage version Al 3P 1x35-120mm²
£58.34 / piece* -
HYS328HL connection terminal Plug-in P160 1P
£30.89 / piece*
-
HXA003H
Shunt trip 100-120V AC (x160-P160-x250-P250-x630-P630)
£247.02 / piece* -
HXA005HShunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)
£185.68 / piece* -
HXA002HShunt trip 48V DC (x160-P160-x250-P250-x630-P630)
£136.93 / piece* -
HXA001HShunt trip 24V DC (x160-P160-x250-P250-x630-P630)
£142.56 / piece* -
HXA004HShunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)
£244.69 / piece*
-
HXA039H
Padlock (x160-P160-x250-P250-x630)
£20.60 / piece* -
HXB070HInterlock mechanical cable 1.0m (P160-x250-h250-h400-h630-h800-h1000)
£96.56 / piece* -
HXB071HInterlock mechanical cable 1.5m (P160-x250-h250-h400-h630-h800-h1000)
£101.51 / piece* -
HXS066HMechanical interlocking front cover P160
£68.62 / piece* -
HXS165HDirect interlocking kit P160 3P
£54.90 / piece*
-
HXA026H
Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
£51.71 / piece* -
HXA021HAuxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
£110.27 / piece* -
HXA024HAlarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
£65.27 / piece* -
HXA025HAuxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
£189.60 / piece*
-
HYA035HConnecting kit 3P/4P
£32.36 / piece*
-
HYS033HDIN Rail adaptator P160 3P/4P
£27.45 / piece*
-
HXS030HDirect rotary handle for P160
£82.35 / piece*
-
HXS031HRotary handle on door for P160
£197.13 / piece*
-
HXS032HDirect rotary handle P160 with interlocking
£144.11 / piece*
-
HYS019HInterphase barrier for P160 3/4P
£15.45 / piece*
-
HYS200HPlug-in base for P160 3P
£199.00 / piece* -
HYS300HPlug-in adaptor for P160 3P (63-160A)
£120.10 / piece* -
HYS310HPlug-in adaptor for P160 3P (16-50A)
£106.37 / piece*
-
HYS256HSafety trip (P160-P250)
£68.62 / piece*
Technical characteristics
Electric current
-
Rated current25 A
-
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-225 kA
-
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-235 kA
-
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-235 kA
-
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-225 kA
-
Rated current 10°C according to IEC 6094730.10 A
-
Rated current 15°C according to IEC 6094729.60 A
-
Rated current 20°C according to IEC 6094728.90 A
-
Rated current 25°C according to IEC 6094728.30 A
-
Rated current 30°C according to IEC 6094727.70 A
-
Rated current at 35°C according to IEC 6094727 A
-
Rated current at 40°C according to IEC 6094726.40 A
-
Rated current 45°C according to IEC 6094725.70 A
-
Rated current 50°C according to IEC 6094725 A
-
Rated current 55°C according to IEC 6094724.30 A
-
Rated current at 60°C according to IEC 6094723.50 A
-
Rated current 65°C according to IEC 6094722.80 A
-
Rated current 70°C according to IEC 6094722 A
Architecture
-
Number of poles3
-
Control/operation elementToggle
-
Device construction typeFixed built-in
-
Neutral positionWithout neutral
Frequency
-
Frequency50 - 60 Hz
Voltage
-
Rated impulse withstand voltage Uimp8,000 V
-
Rated insulation voltage Ui800 V
-
Rated operational voltage Ue220 - 690 V
Functions
-
Trip unitTM A/A
Power
-
Total power loss under IN19.50 W
Endurance
-
Electric endurance in number of cycles10,000
-
Number of mechanical operations40,000
Safety
-
Ingress Protection (IP) classIP4X
Connection
-
Cross-section flexible conductor6 - 70 mm²
-
Cross-section rigid conductor6 - 95 mm²
Connectivity
-
Type of connectionScrew terminal
Cover, door
-
InterlockableYes
Settings
-
Thermal protection knob setting xIN0.63, 0.8, 1
Cable
-
Cable materialCopper
Compatibility
-
Compatible with RDC AOBNo
-
Suitable for DIN RailNo
-
Suitable for distribution boardYes
Dimensions
-
Height130 mm
-
Width90 mm
-
Depth97 mm
Electrical protection
-
Instantaneous protection (li): dial setting coefficient6, 8, 10, 12
Installation, mounting
-
Mounting-/Connection PositionFront
-
Nominal tightening torque6 - 6 Nm
-
Nominal tightening torque down terminal6 - 6 Nm
-
Nominal tightening torque top terminal6 - 6 Nm
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet HHS025DC
Moulded Case Circuit Breaker h3+ P160 TM ADJ 3P3D 25A 25kA CTC
PDF -
Instruction manual
Manual for moulded case circuit breaker h3+ P160 (Date: 2020-03)
Instruction manual International 2016-03-09
PDF4,40 MB
Manual for moulded case circuit breaker h3+ P160 (Date: 2023-03)
Instruction manual International 2023-03-08
PDF7,44 MB -
STEP files
CAD file for MCCB 160A 3P
STEP files International 2023-11-24
STP886,39 kB -
Handbook
Technical catalogue
h3+ Moulded Case Circuit breakers up to 630A
PDF48,86 MB -
Declaration of conformity
Declaration
Declaration of conformity International 2022-02-01
PDF300,00 kB
More documentation
Discover our other products of this range
-
5
-
1
HMW631NRMoulded Case Circuit Breaker h3+ P630 Energy 4P4D N0-50-100% 630A 50kA FTCPrice£3,494.38/ piece * -
2
HMW630NRMoulded Case Circuit Breaker h3+ P630 Energy 3P3D 630A 50kA FTCPrice£2,815.10/ piece * -
3
HMW401NRMoulded Case Circuit Breaker h3+ P630 Energy 4P4D N0-50-100% 400A 50kA FTCPrice£2,535.70/ piece * -
4
HMW400NRMoulded Case Circuit Breaker h3+ P630 Energy 3P3D 400A 50kA FTCPrice£1,908.08/ piece * -
5
HMW251NRMoulded Case Circuit Breaker h3+ P630 Energy 4P4D N0-50-100% 250A 50kA FTCPrice£2,535.70/ piece *
