The Hager h3 x160 TM ADJ 3P3D 40A moulded case circuit breaker protects three-phase feeders against overloads and short-circuits. With Icu 18 kA at 400 V (25 kA at 240 V) and adjustable thermal settings 0.63/0.8/1 x In, it suits industrial/commercial distribution. TM A/F trip unit, 220-415 V, Ui 690 V, Uimp 8 kV. IP4X, 50-60 Hz. Front mounting, screw terminals 4-95 mm². 10k electrical/20k mechanical cycles.
EAN-Nr.
3250613130619
Packaging
1 piece
MCCB h3 x160 3P 40A Icu 18kA TM adj thermal screw terminals HDA040U
Price
£403.52
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Shunt release 5 products available -
Auxiliaries contact block 4 products available -
Under voltage coil 8 products available -
Terminal cover 3 products available -
AOB MCCB type A-HI 2 products available -
Locking interlocking functions 1 products available
Complete your system
-
HXA003H
Shunt trip 100-120V AC (x160-P160-x250-P250-x630-P630)
£259.37 / piece* -
HXA005HShunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)
£194.96 / piece* -
HXA002HShunt trip 48V DC (x160-P160-x250-P250-x630-P630)
£143.78 / piece* -
HXA001HShunt trip 24V DC (x160-P160-x250-P250-x630-P630)
£149.69 / piece* -
HXA004HShunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)
£256.92 / piece*
-
HXA026H
Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
£54.30 / piece* -
HXA021HAuxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
£115.78 / piece* -
HXA024HAlarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
£68.53 / piece* -
HXA025HAuxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
£199.08 / piece*
-
HXA051H
UVR delayed 24V DC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA014HUndervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)
£180.56 / piece* -
HXA055HUVR delayed 380-450V AC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA054HUVR delayed 220-240V AC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA011HUndervoltage release 24V DC (x160-P160-x250-P250-x630-P630)
£147.33 / piece* -
HXA053HUVR delayed 110-120V AC (x160-P160-x250-P250-x630-P630)
£675.70 / piece* -
HXA013HUndervoltage release 100-120V AC (x160-P160-x250-P250-x630-P630)
£159.13 / piece* -
HXA015HUndervoltage release 380-450V AC (x160-P160-x250-P250-x630-P630)
-
HYA021H
Terminal cover x160 3P long
£37.73 / piece* -
HYA023HTerminal cover x160 3P spreader
£59.89 / piece* -
HYA025HTerminal cover x160 3P short
£53.68 / piece*
-
HXA039H
Padlock (x160-P160-x250-P250-x630)
£21.63 / piece*
-
HXA030HDirect rotary handle x160
£91.15 / piece* -
HXA031HExtended rotary handle x160
£159.32 / piece*
-
HYA013HExtended connection x160 4P collar
£63.66 / piece* -
HYA014HSpreader x160 3P collar
£55.06 / piece*
-
HYA019HInterphase barrier x160 3/4P
£30.48 / piece*
-
HYA033HDIN Rail adaptator x160 3P/4P
£33.97 / piece*
Technical characteristics
Electric current
-
Rated current40 A
-
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-218 kA
-
Rated ultimate short-circuit breaking capacity Icu under 240 V AC IEC 60947-225 kA
-
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-225 kA
-
Rated service breaking capacity Ics under 400 V AC according to IEC 60947-218 kA
Architecture
-
Number of poles3
Frequency
-
Frequency50 - 60 Hz
Voltage
-
Rated impulse withstand voltage Uimp8,000 V
-
Rated insulation voltage Ui690 V
-
Rated operational voltage Ue220 - 415 V
Functions
-
Trip unitTM A/F
Power
-
Total power loss under IN11 W
Endurance
-
Electric endurance in number of cycles10,000
-
Number of mechanical operations20,000
Safety
-
Ingress Protection (IP) classIP4X
Connection
-
Cross-section flexible conductor4 - 70 mm²
-
Cross-section rigid conductor4 - 95 mm²
Installation, mounting
-
Mounting-/Connection PositionFront
Connectivity
-
Type of connectionScrew terminal
Settings
-
Thermal protection knob setting xIN0.63, 0.8, 1
Dimensions
-
Height130 mm
-
Width75 mm
-
Depth68 mm
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet HDA040U
