Moulded Case Circuit Breaker h3 x160 TM ADJ 3P3D 25A 18kA CTC
HDA025U
You have to log in with your myHager profile to see prices and to order.
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
-
Neutral position
without neutral
-
-
Rated operational voltage Ue
220 / 415 V
-
-
Rated insulation voltage
690 V
-
Rated impulse withstand voltage
8 kV
-
Rated service breaking capacity Ics under 400V AC according IEC 60947-2
18 kA
-
Depth of installed product
68 mm
-
Height of installed product
130 mm
-
Width of installed product
75 mm
-
Total power loss under IN
13.7 W
-
Electric endurance in number of cycles
1000
-
Number of mechanical operations
4000
-
Type of connection
with screw
-
Number of auxiliary contacts as normally closed contact
0
-
Number of auxiliary contacts as normally open contact
0
-
Number of auxiliary contacts as change-over contact
0
-
-
European directive WEEE
concerned
