- Architecture
- Neutral position
- without neutral
- Number of poles
- 1 P
- Type of pole
- 1 P
- Fixing mode
- Din-Rail
- Curve
- D
-
- Main electrical features
- Rated operational voltage Ue
- 230 / 400 V
- Rated current
- 20 A
- Type of supply voltage
- AC
-
- Voltage
- Rated insulation voltage
- 500 V
- Rated impulse withstand voltage
- 6000 V
-
- Electric current
- Rated service breaking capacity Ics AC according IEC 60898-1
- 7.5 kA
-
- Electric current / temperature
- Rating current 30°C
- 20 A
-
- Dimensions
- Depth of installed product
- 70 mm
- Height of installed product
- 83 mm
- Width of installed product
- 17.5 mm
-
- Power
- Total power loss under IN
- 2.56 W
-
- Endurance
- Electric endurance in number of cycles
- 4000
- Number of mechanical operations
- 20000
-
- Capacity
- Number of modules
- 1
-
- Installation, mounting
- Tightening torque
- 2,8Nm
-
- Equipment
- Can be accessorized
- Yes
-
- Standards
- Standard text
- EN 60898-1
- IEC 60947-2
- European directive WEEE
- concerned
-
- Safety
- Protection index IP
- IP20
-
