MCB 1P 15kA D-125A 1.5M HMD199T
EAN-Nr.
3250613231354
Packaging
1 piece
£95.99
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Architecture
-
Number of poles1 P
-
Type of pole1 P
-
CurveD
Main electrical features
-
Rated operational voltage Ue240 / 415 V
-
Frequency50/60 Hz
-
Type of supply voltageAC
Voltage
-
Rated insulation voltage500 V
-
Rated impulse withstand voltage6000 V
Electric current
-
Rated short circuit breaking capacity Icn under 230V AC according IEC60898-115 kA
Electric current / temperature
-
Rating current 30°C125 A
Dimensions
-
Depth of installed product70 mm
-
Height of installed product90 mm
-
Width of installed product27 mm
Power
-
Total power loss under IN9.93 W
Endurance
-
Electric endurance in number of cycles4000
-
Number of mechanical operations20000
Installation, mounting
-
Tightening torque3,5 to 5Nm
Connection
-
Connection cross-sect. flexible conductor50mm²
-
Connection cross-sect. rigid cable70mm²
-
Type of connectionterminal with tightening compensation system
Standards
-
Standard textEN 60898-1 ; IEC 60947-2 ; AS/NZS 60898-1
-
European directive WEEEnot concerned
Safety
-
Protection index IPIP20
