Alarm contact for motor starter 2C MZ527N
EAN-Nr.
3250614565120
Packaging
1 piece
Price
£32.86
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Main electrical features
-
Rated operational voltage Ue220 / 500 V
-
Frequency40/60 Hz
-
Type of supply voltageAC
Voltage
-
Rated insulation voltage690 V
-
Rated impulse withstand voltage6000 V
Electric current
-
Acceptable current rating with AC13 A
Dimensions
-
Depth of installed product68 mm
-
Width of installed product9 mm
Power
-
Total power loss under IN0.2 W
Endurance
-
Electric endurance in number of cycles5000
-
Number of mechanical operations10000
Installation, mounting
-
Tightening torque1,3Nm
Connection
-
Connection cross-sect. flexible conductor2,5mm²
-
Connection cross-sect. rigid cable2,5mm²
-
Type of connectionwith screw
-
Type of contacts2NO
Equipment
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as normally open contact2
-
Number of auxiliary contacts as change-over contact0
Use conditions
-
Operating temperature-25…55 °C
Downloads
-
Product image
-
Technical brochures
Technical brochure
Brochure for contactors / motor protection switches (EN, 2021-11)
PDF28 MB -
Catalogue
Commercial Distribution Catalogue
PDF14 MB -
Declaration of conformity
EU Declaration of conformity for MZ527N
Declaration Of Conformity
PDF426 KB
EU Declaration of conformity for MZ527N
Declaration
PDF433 KB
EU Declaration of conformity for MZ527N
PDF442 KB
EU Declaration of conformity for MZ527N
Declaration
PDF118 KB -
RoHS report
Pollutant guidelines for MZ527N
REACH declaration MZ527N (english)
PDF103 KB
More documentation
