Motor protection circuit breaker 3P 0.1-0.16A ; 0.02/0.03 kW at 230/415V MM501N
EAN-Nr.
3250614435140
Packaging
1 piece
Price
£164.73
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Architecture
-
Number of poles3 P
-
Type of pole3 P
Main electrical features
-
Rated operational voltage Ue690 V
-
Frequency50/60 Hz
-
Type of supply voltageAC
Voltage
-
Rated insulation voltage690 V
-
Rated impulse withstand voltage6000 V
Electric current
-
Rated service breaking capacity Ics under 400V AC according IEC 60947-2150 kA
Power
-
Total power loss under IN5.39 W
Endurance
-
Electric endurance in number of cycles50000
-
Number of mechanical operations100000
Installation, mounting
-
Tightening torque1,7Nm
Connection
-
Type of connectionwith screw
Equipment
-
Can be accessorizedYes
Standards
-
Standard textIEC 60947-4-1 ; EN 60947-4-1
-
European directive RoHsvoluntary compliance
Use conditions
-
Operating temperature-25…55 °C
