250A 2+10 Way Hybrid TPN c/w SD Glazed • JK20210BGSD | Hager
Location United-Kingdom

  • Better buildings. Better tomorrows.

    • Menu
    Account
    EAN-Nr.
    5015652601210
    Packaging
    1 piece

    250A 2+10 Way Hybrid TPN With Switch Disconnector and Glazed Door JK20210BGSD

    Complete your system

    Optional accessories

  • See more (31)
    • Insert for lock system 1 products available
    • Small equipped distri­bu­tion board 9 products available
    • Gland plate for enclosure 3 products available
    • Distrib­utor assembly with main switch 1 products available
    • Trans­ition cover section for install­a­tion duct 2 products available
    • Cable entry cabinet 6 products available

    Technical characteristics

    Install­a­tion, mounting
    • Mounting on
      Surface mounting
    Func­tions
    • Has protec­tion main switch
      Yes
    • Over­voltage protec­tion
      No
    Capa­city
    • Number of modules
      36
    Elec­tric current
    • Rated current
      250 A
    Dimen­sions
    • Depth
      165.50 mm
    • Height
      1,250 mm
    • Width
      465 mm
    • Thick­ness of side­wall
      0.90 mm
    Cover, door
    • Inter­lock­able
      No
    • Door/­cover is trans­parent
      Yes
    Mater­ials
    • RAL code
      7035
    • Colour
      Light grey
    • Material
      Steel
    Connec­tion
    • Number of access­ible phases
      3
    Scope of delivery
    • Number of RCCB in enclosure
      0
    Equip­ment
    • With socket outlet
      No
    Safety
    • Ingress Protec­tion (IP) class
      IP30
    • Protec­tion class
      Isol­a­tion class I
    • Number of earth leakage switches 300 mA
      0

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes

    Certifications and documents

    PEP - 125A 4 Way TPN Board c/w SD & SPD (English)
    PDF
    17,17 MB
    REACH declaration JK20210BGSD
    PDF
    RoHS report JK20210BGSD
    PDF
