Moulded Case Circuit Breaker h1600 3P 50kA 1600A LSI HNF990H

EAN-Nr.
3250613349905
Packaging
1 Prt.
Price
£2,751.24
/ piece *

Technical characteristics

Architecture
  • Number of poles
    3 P
Main electrical features
  • Rated operational voltage Ue
    220 / 690 V
  • Frequency
    50/60 Hz
Voltage
  • Rated insulation voltage
    800 V
  • Rated impulse withstand voltage
    8 kV
Power
  • Total power loss under IN
    168.9 W
Endurance
  • Electric endurance in number of cycles
    1000
  • Number of mechanical operations
    4000
Connection
  • Type of connection
    Terminal
Equipment
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Number of auxiliary contacts as change-over contact
    0
Standards
  • European directive WEEE
    concerned
Safety
  • Protection index IP
    IP4X
Use conditions
  • Operating temperature
    -25…70 °C

Downloads

  • Product image

    Image HNF990H  | Hager

    Product Image HNF990H

  • Product notice

    Image Instruction manuals for HNF990H  | Hager

    Instruction manuals for HNF990H

    PDF
    3 MB
More documentation
*Data is subject to errors and technical modifications. Prices are trade price, exclusive of VAT.
