HNF980H

Moulded Case Circuit Breaker h1600 3P 50kA 1250A LSI
EAN
3250613349899
Quantity
1
This product is now obsolete. However, this page remains available for information purposes. If you require any further information please contact the Technical Service Centre by email or on 01952 675689.
  • Architecture
    • Number of poles
      3 P
    • Type of pole
      3P3D
  • Main electrical features
    • Rated operational voltage Ue
      220 / 690 V
    • Frequency
      50;60 Hz
    • Rated current
      1250 A
  • Voltage
    • Rated insulation voltage
      800 V
    • Rated impulse withstand voltage
      8000 V
  • Power
    • Total power loss under IN
      187.5 W
  • Endurance
    • Electric endurance in number of cycles
      1000
    • Number of mechanical operations
      4000
  • Capacity
    • Number of modules
      12
  • Cover, door
    • Interlockable
      No
  • Installation, mounting
    • Tightening torque
      65Nm
  • Connection
    • Connection cross-sect. flexible conductor
      3x240mm²
    • Connection cross-sect. rigid cable
      3x240mm²
    • Type of connection
      Terminal
  • Equipment
    • Number of auxiliary contacts as normally closed contact
      0
    • Number of auxiliary contacts as normally open contact
      0
    • Number of auxiliary contacts as change-over contact
      0
    • Can be accessorized
      No
  • Standards
    • Standard text
      IEC 60947-2
    • European directive WEEE
      concerned
  • Safety
    • Protection index IP
      IP4X
  • Use conditions
    • Storage temperature
      -35/70 °C
  • Temperature
    • Operating temperature
      -25/70 °C
