HNE801H

Moulded Case Circuit Breaker h1000 4P 50kA 800A LSI
EAN
3250613349752
Quantity
1
Trade price*
£3,059.41 *
Architecture
Number of poles4 P
Type of pole4P4D N:0;50;100%
Main electrical features
Rated operational voltage Ue220 / 690 V
Frequency50;60 Hz
Rated current800 A
Voltage
Rated insulation voltage800 V
Rated impulse withstand voltage8000 V
Power
Total power loss under IN153.6 W
Endurance
Electric endurance in number of cycles1000
Number of mechanical operations4000
Capacity
Number of modules16
Cover, door
InterlockableNo
Installation, mounting
Tightening torque65Nm
Connection
Connection cross-sect. flexible conductor2x240mm²
Connection cross-sect. rigid cable2x240mm²
Type of connectionTerminal
Equipment
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Can be accessorizedNo
Standards
Standard textIEC 60947-2
European directive WEEEconcerned
Safety
Protection index IPIP4X
Use conditions
Storage temperature-35/70 °C
Temperature
Operating temperature-25/70 °C
See more features
