EPN525 - Latching relay 2NC+2NO 230V
Image EPN525 of the product Hager | Hager
Image EPN525 of the product Hager | Hager
EPN525 - Latching relay 2NC+2NO 230V
Image EPN525 of the product Hager | Hager
Image EPN525 of the product Hager | Hager

Latching relay 2NC+2NO 230V EPN525

EAN-Nr.
3250612369485
Packaging
1 piece
Price
£135.98
/ piece *

Technical characteristics

Main electrical features
  • Rated operational voltage Ue
    250 V
  • Frequency
    50/60 Hz
Voltage
  • Rated insulation voltage
    400 V
Dimensions
  • Depth of installed product
    63 mm
  • Height of installed product
    83 mm
  • Width of installed product
    35 mm
Power
  • Total power loss under IN
    2.4 W
Endurance
  • Number of mechanical operations
    500000
Fluorescent bulbs control
  • Max. power with fluorescent parallel lamps
    900 VA
Incandescent bulbs control
  • Max. power with incandescent lamps
    1800 W
Connection
  • Number of contacts
    4
Standards
  • Standard text
    IEC/EN 60669-2
  • European directive WEEE
    concerned
Safety
  • Protection index IP
    IP20
Use conditions
  • Operating temperature
    -5…40 °C

Downloads

More documentation
*Data is subject to errors and technical modifications. Prices are trade price, exclusive of VAT.
