| Protection index IP | IP20 |
|---|---|
| With transparent product label holder | Yes |
| Rated conditional short-circuit current Inc according to EN 61008-1 | 6 kA |
| Depth of installed product | 70 mm |
| Power loss per pole at In | 0.7 W |
| Protected against nuisance tripping | No |
| Rated current | 25 A |
| Ground fault signalisation | yes |
| Total power loss under IN | 1.3 W |
| CE marking on label | AI2_B5_CE_01.JPG |
| Width of installed product | 35 mm |
| Withstand not tripping on 8-20 μs wave | 0.25 kA |
| 360° product mounting position | Yes |
| Rated residual operating current | 100 mA |
| Neutral position | right |
| Quantity of half modules of 17,7mm | 4 |
| Breaking and opening capacity | 1500 A |
| Height of installed product | 83 mm |
| Frequency | 50 Hz |
| Frequency (range for ETIM) | 50 Hz |
| Short-time delayed tripping | No |
| Operating temperature | -25/40 °C |
| Residual current trip mode | Undelayed |
| Degree of pollution according to IEC 60664 / IEC 60947-2 | 2 |
| Tightening torque | 2,8Nm |
| Construction size (DIN 43880) | 1 |
| Fixing mode | DIN rail type O (symmetrical) |
| Rating current 30°C | 25 A |
| Rated impulse withstand voltage | 4000 V |
| Operating temperature | -25/40 °C |
| Altitude | 2000 m |
| Number of modules | 2 |
| Rated insulation voltage | 500 V |
| Rated operational voltage Ue | 230 V |
| Residual current type | A |
| Type of connection | with screw |
| Number of mechanical operations | 4000 |
| European directive WEEE | concerned |
| Storage temperature | -55/70 °C |
| Standard text | BS 61008-1 ; EN 61008-1 |
| Storage/transport temperature | -55/70 °C |
| Connection cross-section of the access with screws, with flexible conductor | 1 / 16 mm² |
| Connection cross-sect. flexible conductor | 1 ; 16mm² |
| Number of poles | 2 P |
| Electric endurance in number of cycles | 2000 |
| Connection cross section of access and exit with screws, for flexible conductor | 1 / 16 mm² |
| Connection cross-section for rigid conductor, upstream terminals with screws | 1 / 25 mm² |
| Connection cross-section at output with screw, for massive conductor | 1 / 25 mm² |
| Connection cross-sect. rigid cable | 1 ; 25mm² |
| Bottom removability for modular devices | No |
| Rating current 0°C | 25 A |
| Rating current -10°C | 25 A |
| Rating current 10°C | 25 A |
| Rating current -15°C | 25 A |
| Rating current 15°C | 25 A |
| Rating current -20°C | 25 A |
| Rating current 20°C | 25 A |
| Rating current -25°C | 25 A |
| Rating current 25°C | 25 A |
| Rating current 35°C | 25 A |
| Rating current 40°C | 25 A |
| Rating current 45°C | 25 A |
| Rating current -5°C | 25 A |
| Rating current 50°C | 25 A |
| Rating current 5°C | 25 A |
| Rating current 55°C | 25 A |
| Rating current 60°C | 25 A |
| Rating current 65°C | 25 A |
| Rating current 70°C | 21 A |
| Sealable | Yes |
| Top removability for modular devices | No |
| Type of Bottom Connection for modular devices | BIconnect |
| Type of bottom rail clip for modular devices | metallic |
| Type of top connection for modular devices | with screw |
| EAN | 3250611614500 |
| Unit | PCE |
| Sales status | 3C |
