4-pole, 25A Modular Switch SBN425

EAN-Nr.

3250615510112

Packaging

1 piece

Price

£51.62

/ piece *

Technical characteristics
Documentations
Accessories
More products

Download the sheet

Technical characteristics

Neutral position

without neutral
Number of poles

4 P
Type of pole

4 P

Rated operational voltage Ue

400 V
Frequency

50/60 Hz

Rated insulation voltage

440 V
Rated impulse withstand voltage

4000 V

Depth of installed product

68 mm
Height of installed product

83 mm
Width of installed product

35 mm

Total power loss under IN

3.6 W

Electrical durability at nominal load in AC22 in operating cycles

25000
Number of mechanical operations

200000

Tightening torque

1,8Nm

Connection cross-sect. flexible conductor

1,5 / 10mm²
Connection cross-sect. rigid cable

1,5 / 16mm²
Type of connection

with screw

Standard text

IEC 60947-3

Operating temperature

-20…50 °C

Downloads

Product image

Product Image SBN425
Product data sheet

Product data sheets for SBN425

UK_PD_TDS_LoadBreakDisconnectors.pdf

PDF

58 KB
Product licence

Product licence for SBN425

Licence for NETHERLANDS

PDF

2 MB

Product licence for SBN425

Licence for NETHERLANDS

PDF

2 MB
Declaration of conformity

EU Declaration of conformity for SBN425

Declaration

PDF

311 KB

EU Declaration of conformity for SBN425

Declaration

PDF

931 KB

EU Declaration of conformity for SBN425

Manufacturer declaration switch disconnector march 2024

PDF

176 KB
PEP document

Product environmental profile for SBN425

PDF

440 KB
RoHS report

Pollutant guidelines for SBN425

RoHS declaration SBN425 (english)

PDF

103 KB

More documentation

*Data is subject to errors and technical modifications. Prices are trade price, exclusive of VAT.
