2-pole, 63A Modular Switch SBN263
EAN-Nr.
3250615510211
Packaging
6 PCEs
£51.28
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Architecture
-
Neutral positionwithout neutral
-
Number of poles2 P
-
Type of pole2 P
Main electrical features
-
Rated operational voltage Ue400 V
-
Frequency50/60 Hz
Voltage
-
Rated insulation voltage440 V
-
Rated impulse withstand voltage6000 V
Dimensions
-
Depth of installed product68 mm
-
Height of installed product83 mm
-
Width of installed product35 mm
Power
-
Total power loss under IN4.6 W
Endurance
-
Electrical durability at nominal load in AC22 in operating cycles5000
-
Number of mechanical operations60000
Installation, mounting
-
Tightening torque2,8Nm
Connection
-
Connection cross-sect. flexible conductor2,5 / 16mm²
-
Connection cross-sect. rigid cable2,5 / 25mm²
-
Type of connectionwith screw
Standards
-
Standard textIEC 60947-3 ; IEC/EN 60669-2 ; IEC/EN 60669-4
Use conditions
-
Operating temperature-20…50 °C
Downloads
-
Product image
-
Product data sheet
Product data sheets for SBN263
UK_PD_TDS_LoadBreakDisconnectors.pdf
PDF58 KB -
Product licence
Product licence for SBN263
Licence for NETHERLANDS
PDF2 MB
Product licence for SBN263
Licence for NETHERLANDS
PDF2 MB -
Declaration of conformity
EU Declaration of conformity for SBN263
Declaration
PDF311 KB
EU Declaration of conformity for SBN263
Declaration
PDF931 KB
EU Declaration of conformity for SBN263
Manufacturer declaration switch disconnector march 2024
PDF176 KB -
PEP document
Product environmental profile for SBN263
PDF440 KB -
RoHS report
Pollutant guidelines for SBN263
RoHS-declaration 2023-10-20 (english)
PDF32 KB
Pollutant guidelines for SBN263
REACH-declaration 2023-10-20 (english)
PDF32 KB
More documentation
