| Closing ability with 400V in AC23A | 677 A |
|---|---|
| Rated short-time withstand current 1s | 0.48 kA |
| Rated short-circuit making capacity Icm under 240V AC according IEC 60947-3 | 677 A |
| Rated current | 32 A |
| Short-circuit current with gI-gG fuses | 480 A |
| Protection index IP | IP20 |
| Cage clamp position | off set |
| Thermal rated current outside of housings | 32 A |
| European directive WEEE | concerned |
| Height of installed product | 83 mm |
| Altitude | 2000 m |
| Rated operational current in AC21 category A | 32 A |
| Rated operational current in AC21category B | 32 A |
| Acceptable current rating with AC22 category A | 32 A |
| Acceptable current rating with AC22 category B | 32 A |
| Frequency | 50;60 Hz |
| Tightening torque | 1,8Nm |
| Degree of pollution according to IEC 60664 / IEC 60947-2 | 2 |
| Electrical durability at nominal load in AC21in operating cycles | 25000 |
| Electrical durability at nominal load in AC22 in operating cycles | 25000 |
| Frequency (range for ETIM) | 50/60 Hz |
| Device family | SBN |
| Width of installed product | 17.5 mm |
| Number of mechanical operations | 200000 |
| Operating temperature | -20/50 °C |
| Rated impulse withstand voltage | 4000 V |
| With signal lamp | No |
| Rated operational voltage Ue | 230 V |
| Storage temperature | -40/80 °C |
| Number of poles | 1 P |
| Standard text | IEC 60947-3 ; IEC ; EN 60669-2 ; IEC ; EN 60669-4 |
| Connection cross-sect. flexible conductor | 1,5 ; 10mm² |
| Connection cross-sect. rigid cable | 1,5 ; 16mm² |
| Type of voltage input 1 | AC |
| Quantity of NO contacts | 1 |
| Type of pole | 1 P |
| Quantity of NC contacts | 0 |
| Quantity of INV contacts | 0 |
| Total power loss under IN | 1.5 W |
| Power loss per pole at In | 1.5 W |
| Depth of installed product | 68 mm |
| Neutral position | without neutral |
| Type of order | Break switch |
| Type of connection | with screw |
| Number of modules | 1 |
| Quantity of half modules of 17,7mm | 2 |
| Rated insulation voltage | 440 V |
| Unit | PCE |
| EAN | 3250615510129 |
| Sales status | 3C |
