JK2 32 Module DIN Rail Box Glazed JK232EG

EAN-Nr.
5015652252726
Packaging
1 piece
Price
£270.61
/ piece *
£270.61
/ piece *

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

JK2 32 Module DIN Rail Box Glazed

JK232EG

  • Accessories
  • Technical characteristics
  • Environmental value
  • Documentations
  • More products
Download the sheet

Complete your system

Compatible products

  • Referenced by 5 products available

Referenced by

  • JK224BG

    250A 24 Way TPN Board Glazed Door
    £1,007.10  / piece*
  • JK218BG

    250A 18 Way TPN Board Glazed Door
    £734.61  / piece*
  • JK216BG

    250A 16 Way TPN Board Glazed Door
    £632.56  / piece*
  • JK212BG

    250A 12 Way TPN Board Glazed Door
    £444.70  / piece*
  • JK208BG

    250A 8 Way TPN Board Glazed Door
    £384.43  / piece*

Technical characteristics

Install­a­tion, mounting
  • Suit­able for outdoor usage
    No
  • Mounting on
    Surface mounting
Equip­ment
  • Number of rails
    2
  • Number of rows
    2
  • Number of section in width
    1
  • With lock
    Yes
  • Has neutral terminal block
    Yes
  • Has earthing terminal block
    Yes
Capa­city
  • Number of modules
    32
Dimen­sions
  • Height
    450 mm
  • Width
    465 mm
  • Depth
    165.50 mm
  • Number of width units
    32
Cover, door
  • Number of cabinet doors
    1
  • Door/­cover is trans­parent
    Yes
Mater­ials
  • Material
    Steel
  • RAL code
    7035
  • Colour
    Light grey
Safety
  • Protec­tion class
    Isol­a­tion class III
  • Impact resist­ance IK
    IK05
  • Ingress Protec­tion (IP) class
    IP3X
  • Locking type
    Key lock, Quarter turn lock

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes
REACh-SVHC free Yes

Certifications and documents

Hager REACH declaration JK232EG
PDF
Hager RoHS report JK232EG
PDF

Downloads

  • Product image

    Image JK232EG | Hager

    Product Image JK232EG

  • Product datasheet

    Image Hager Product data sheet JK232EG | Hager

    Hager Product data sheet JK232EG

    JK2 32 Module DIN Rail Box Glazed

    PDF

  • BIM Revit objects

    Image Range : Type B TP&N Distribution Boards. Switchboard with DIN rail system. English - Hosted family - REVIT Family 2020 - V2022 | Hager

    Range : Type B TP&N Distribution Boards. Switchboard with DIN rail system. English - Hosted family - REVIT Family 2020 - V2022

    BIM Revit objects en-GB 2024-03-22

    RFA
    1,24 MB
    Image Range : Type B TP&N Distribution Boards. Switchboard with DIN rail system. English - Non hosted family - REVIT Family 2020 - V2022 | Hager

    Range : Type B TP&N Distribution Boards. Switchboard with DIN rail system. English - Non hosted family - REVIT Family 2020 - V2022

    BIM Revit objects en-GB 2024-03-22

    RFA
    1,23 MB
    Image Range Typ.B TP&N DIN Extension Boxes 250A -Revit Family 2020 hosted-V2021 | Hager

    Range Typ.B TP&N DIN Extension Boxes 250A -Revit Family 2020 hosted-V2021

    BIM Revit objects en-GB 2020-01-01

    RFA
    1,23 MB
    Image Range Typ.B TP&N DIN Extension Boxes 250A -Revit Family 2020 no hosted-V2021 | Hager

    Range Typ.B TP&N DIN Extension Boxes 250A -Revit Family 2020 no hosted-V2021

    BIM Revit objects en-GB 2020-01-01

    RFA
    1,22 MB

  • Product data sheet

    Image UK_CD_TDS_DINEXTCABLESPREADER.pdf | Hager

    UK_CD_TDS_DINEXTCABLESPREADER.pdf

    Technical data sheet including dimensions for DIN extension and cable spreader boxes.

    PDF
    77,62 kB

  • Declaration of conformity

    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2021-09-29

    PDF
    276,98 kB
    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2021-09-29

    PDF
    269,32 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    302,50 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    296,11 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    278,56 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    288,18 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    248,06 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    253,91 kB
