HND400H

Moulded Case Circuit Breaker h630 3P 50kA 400A LSI
EAN
3250613349547
Quantity
1
Trade price*
£1,071.74 /prt.*
  • Architecture
    • Number of poles
      • 3 P
  • Main electrical features
    • Rated operational voltage Ue
      • 220 / 690 V
    • Frequency
      • 50/60 Hz
    • Rated current
      • 400 A
  • Voltage
    • Rated insulation voltage
      • 800 V
  • Power
    • Total power loss under IN
      • 62.4 W
  • Endurance
    • Number of mechanical operations
      • 4000
  • Capacity
    • Number of modules
      • 8
  • Installation, mounting
    • Tightening torque
      • 22Nm
  • Connection
    • Connection cross-sect. flexible conductor
      • 35 / 240mm²
    • Connection cross-sect. rigid cable
      • 35 / 240mm²
    • Type of connection
      • Terminal
  • Equipment
    • Number of auxiliary contacts as normally closed contact
      • 0
    • Number of auxiliary contacts as normally open contact
      • 0
    • Number of auxiliary contacts as change-over contact
      • 0
  • Standards
    • Standard text
      • IEC 60947-2
    • European directive WEEE
      • concerned
  • Safety
    • Protection index IP
      • IP4X
