EMN001

Stair case time lag switch
EAN
3250612339969
Quantity
6
Trade price*
£70.08 /prt.*
Architecture
Fixing modeDin-Rail
Configuration
Switch modeNO contact
Main electrical features
Rated operational voltage Ue230 V
Frequency50;60 Hz
Rated current16 A
Voltage
Supply voltage230V AC
Electric current
Acceptable current rating with AC116 A
Dimensions
Depth of installed product64 mm
Length64 mm
Width of installed product17.5 mm
Frequency
Frequency50;60 Hz
Power
Max. power with fluo uncompensated lamps3600 VA
Power consumed1 VA
Total power loss under IN2 W
Power dissipation per coil0.25 W
Capacity
Number of modules1
Power supply
Supply voltage 230 V
Fluorescent bulbs control
Max. power with fluorescent parallel lamps1000 VA
Incandescent bulbs control
Max. power with incandescent lamps2300 W
Installation, mounting
Mounting typedin-Rail
Connection
Connection cross-sect. flexible conductor1 ; 6mm²
Connection cross-sect. rigid cable1,5 ; 10mm²
Type of connectionwith screw
Connection type3 and 4 wires
Number of contacts1
Type of contacts1NO
Type of connectionwith screw terminals
Settings
Time delayed range30s ; 10min
Safety
Protection index IPIP20
Use conditions
Operating temperature-10/55 °C
Storage temperature-20/60 °C
temperatur
Operating temperature-10/55 °C
