ECP380D

3 Phase kWhmeter direct 80A 4M S0 MID
EAN
3250612231416
Quantity
1
Trade price*
£293.55 /prt.*
  • Architecture
    • Number of poles
      • 4 P
    • Type of pole
      • 3P / 3P+N
    • Fixing mode
      • DIN rail type O (symmetrical)
  • Main electrical features
    • Rated operational voltage Ue
      • 92 / 480 V
    • Frequency
      • 50 Hz
    • Rated current
      • 80 A
    • Type of supply voltage
      • AC
  • Voltage
    • Max operating voltage
      • 300 V
    • Rated impulse withstand voltage
      • 6 kV
  • Dimensions
    • Depth of installed product
      • 60 mm
    • Height of installed product
      • 92 mm
    • Width of installed product
      • 72 mm
  • Power
    • Power consumed
      • 2 VA
    • Total power loss under IN
      • 0.6 W
  • Measurement
    • Type of measuring instrument
      • electronical
  • Capacity
    • Number of modules
      • 4
  • Power supply
    • Supply voltage
      • 400 V ± 20%
  • Installation, mounting
    • Tightening torque
      • 2Nm
    • Mounting type
      • din-Rail
  • Equipment
    • Type of display
      • retro illuminated display
    • Type of counter
      • 4 wires counter
  • Standards
    • Standard text
      • EN 50470-1 / 3
      • IEC 62053-21 / 23
      • IEC 61557-12
    • European directive WEEE
      • concerned
  • Safety
    • Protection index IP
      • IP20
    • Protection class
      • isol.class II
  • Use conditions
    • Operating temperature
      • -25…55 °C
Documentations
EU Declaration of conformity for ECP380D 54 KBPDFDownload
EU Declaration of conformity for ECP380D 245 KBPDFDownload
Product environmental profile for ECP380D 429 KBPDFDownload
Instruction manuals for ECP380D 1 MBPDFDownload
Commercial Distribution Catalogue 13 MBPDFDownload
More documentation

Share your latest install with the #HagerGang

Join the gang

Specifying Hager

We offer a range of product solutions for any project.
Find out how we can provide you with the ideal electrical solution for your next project.

Explore solutions

Catalogues & brochures

All product documentation and datasheets just one click away!

Explore
*Data is subject to errors and technical modifications. Prices are trade price, exclusive of VAT.
