RCBO with dangerous arc detection 1M 16A B curve 6kA Type A 30mA ARR916U
EAN-Nr.
3250611044789
Packaging
1 piece
Price
£198.50
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Architecture
-
Neutral positionright
-
Number of poles2 P
-
Type of pole1P+N
-
CurveB
Main electrical features
-
Rated operational voltage Ue230 V
-
Type of supply voltageAC
Voltage
-
Rated insulation voltage400 V
-
Max operating voltage253 V
-
Rated impulse withstand voltage4 kV
Electric current
-
Rated residual operating current30 mA
Electric current / temperature
-
Rating current 30°C16 A
Dimensions
-
Depth of installed product70 mm
-
Height of installed product125 mm
-
Width of installed product17.5 mm
Power
-
Total power loss under IN3.82 W
Endurance
-
Electric endurance in number of cycles2000
-
Number of mechanical operations8000
Equipment
-
Quick connectno
-
Can be accessorizedNo
Standards
-
Standard textEN 62606 ; EN 61009-1
Safety
-
Residual current typeA
Use conditions
-
Operating temperature-25…70 °C
