- Architecture
- Number of poles
- 1 P
- Type of pole
- N
- Fixing mode
- DIN rail type O (symmetrical)
-
- Main electrical features
- Rated operational voltage Ue
- 230 / 400 V
- Rated current
- 125 A
- Type of supply voltage
- AC
-
- Voltage
- Rated insulation voltage
- 440 V
- Rated impulse withstand voltage
- 4 kV
-
- Dimensions
- Depth of installed product
- 60 mm
- Height of installed product
- 83 mm
- Width of installed product
- 17.5 mm
-
- Capacity
- Number of modules
- 1
-
- Installation, mounting
- Tightening torque
- 3,6Nm
-
- Standards
- European directive WEEE
- concerned
-
- Safety
- Protection index IP
- IP20
-
- Use conditions
- Operating temperature
- -20…50 °C
-
