HND631H - Moulded Case Circuit Breaker h630 4P 50kA 630A LSI
HND631H - Moulded Case Circuit Breaker h630 4P 50kA 630A LSI

Moulded Case Circuit Breaker h630 4P 50kA 630A LSI HND631H

EAN-Nr.
3250613349585
Packaging
1 Prt.
£3,377.70
/ piece *

Technical characteristics

Architecture
  • Number of poles
    4 P
  • Type of pole
    4P4D N:0/50/100%
Main electrical features
  • Rated operational voltage Ue
    220 / 690 V
  • Frequency
    50/60 Hz
Voltage
  • Rated insulation voltage
    800 V
  • Rated impulse withstand voltage
    8 kV
Power
  • Total power loss under IN
    120 W
Endurance
  • Electric endurance in number of cycles
    1000
  • Number of mechanical operations
    4000
Connection
  • Connection cross-sect. flexible conductor
    35 / 240mm²
  • Connection cross-sect. rigid cable
    35 / 240mm²
Equipment
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Number of auxiliary contacts as change-over contact
    0
Standards
  • Standard text
    IEC 60947-2
  • European directive WEEE
    concerned
Use conditions
  • Operating temperature
    -25…70 °C

Downloads

More documentation
*Data is subject to errors and technical modifications. Prices are trade price, exclusive of VAT.
