HHA030Z

Moulded Case Circuit Breaker h3 x160 TM FIX 1P1D 32A 25kA CTC
EAN
3250613135973
Quantity
1
This product is now obsolete. However, this page remains available for information purposes. If you require any further information please contact the Technical Service Centre by email or on 01952 675689.
  • Architecture
    • Number of poles
      1 P
    • Type of pole
      1P1D
    • Fixing mode
      DIN rail type O or type J
  • Main electrical features
    • Rated operational voltage Ue
      220 V
      240 V
    • Frequency
      50/60 Hz
    • Rated current
      32 A
  • Voltage
    • Rated insulation voltage
      690 V
    • Rated impulse withstand voltage
      8000 V
  • Electric current
    • Rated service breaking capacity Ics under 400V AC according IEC 60947-2
      20 kA
  • Dimensions
    • Depth of installed product
      68 mm
    • Height of installed product
      130 mm
    • Width of installed product
      25 mm
  • Power
    • Total power loss under IN
      3 W
  • Tripping
    • Short-time delayed tripping
      No
  • Endurance
    • Electric endurance in number of cycles
      1000
    • Number of mechanical operations
      4000
  • Cover, door
    • Interlockable
      No
  • Connection
    • Type of connection
      with screw
  • Equipment
    • Can be accessorized
      Yes
  • Standards
    • Standard text
      IEC 60947-2
    • European directive WEEE
      concerned
  • Safety
    • Protection index IP
      IP4X
