Moulded Case Circuit Breaker h3 x160 TM FIX 1P1D 25A 25kA CTC HHA023Z

EAN-Nr.
3250613135966
Packaging
1 Prt.
Price
£215.54
/ piece *

Technical characteristics

Architecture
  • Neutral position
    without neutral
  • Number of poles
    1 P
Main electrical features
  • Rated operational voltage Ue
    220 / 240 V
  • Frequency
    50/60 Hz
  • Type of supply voltage
    AC
Voltage
  • Rated insulation voltage
    690 V
  • Rated impulse withstand voltage
    8 kV
Electric current
  • Rated service breaking capacity Ics under 400V AC according IEC 60947-2
    20 kA
Dimensions
  • Depth of installed product
    68 mm
  • Height of installed product
    130 mm
  • Width of installed product
    25 mm
Power
  • Total power loss under IN
    4.3 W
Endurance
  • Electric endurance in number of cycles
    1000
  • Number of mechanical operations
    4000
Installation, mounting
  • Tightening torque
    6Nm
Connection
  • Connection cross-sect. rigid cable
    6 / 95mm²
  • Type of connection
    with screw
Cable
  • Cable Material
    Cu
Equipment
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Can be accessorized
    Yes
Standards
  • European directive WEEE
    concerned
Safety
  • Protection index IP
    IP4X
