HDA078Z

Moulded Case Circuit Breaker h3 x160 TM FIX 1P1D 80A 18kA CTC
EAN
3250613135911
Quantity
1
Trade price*
£150.66 /prt.*
More Information
Frequency (range for ETIM)50/60 Hz
Rating current 35°C according to IEC 60947-291 A
Can be accessorizedYes
DIN rail mounting with optional adaptatorNo
Altitude2000 m
Thermal protection nob setting xIN1
Degree of pollution according to IEC 60664 / IEC 60947-23
Rated ultimate short-circuit breaking capacity Icu under 230V AC IEC 60947-225 kA
Rated service breaking capacity Ics under 415V AC according IEC 60947-218 kA
Rated service breaking capacity Ics under 380V AC according IEC 60947-218 kA
Rated ultimate short-circuit breaking capacity Icu under 240V AC IEC 60947-225 kA
Rated ultimate short-circuit breaking capacity Icu under 380V AC IEC 60947-218 kA
Rated ultimate short-circuit breaking capacity Icu under 415V AC IEC 60947-218 kA
Rated current80 A
Rated service breaking capacity Ics under 400V AC according IEC 60947-218 kA
Rating current 10°C according to IEC 60947-2106.9 A
Rating current 150°C according to IEC 60947-2103.9 A
Trip UnitTM F;F
Rating current 20°C according to IEC 60947-2100.9 A
Rated service breaking capacity Ics under 240V AC according IEC 60947-225 kA
Rated service breaking capacity Ics under 230V AC according IEC 60947-225 kA
Rated service breaking capacity Ics under 220V AC according IEC 60947-225 kA
Height of installed product130 mm
Frequency50;60 Hz
Number of protected poles1
Rated ultimate short-circuit breaking capacity Icu under 400V AC IEC 60947-218 kA
Rating current 30°C according to IEC 60947-294.4 A
Type of pole1P1D
Critical distance switching emission/earthed part left50 mm
Power loss per pole at In4.8 W
Depth of installed product68 mm
With under voltage releaseNo
Number of mechanical operations4000
Electric endurance in number of cycles1000
Number of poles1 P
Fixing modeDIN rail type O or type J
Critical distance switching emission/between products sides0 mm
Critical distance switching emission/live part50 mm
Critical distance switching emission/insulated plate30 mm
Critical distance switching emission/earthed part top40 mm
Critical distance switching emission/earthed part right50 mm
Critical distance switching emission/earthed part bottom40 mm
Number of auxiliary contacts as change-over contact0
Width of installed product25 mm
Temperature of calibration50 °C
Range of the thermal adjustment80 A
Range of the magnetic adjustment1000 A
Protection index IPIP4X
Rating current 70°C according to IEC 60947-262.2 A
Rating current 65°C according to IEC 60947-267.1 A
Rating current 60°C according to IEC 60947-271.6 A
Rating current 55°C according to IEC 60947-275.9 A
Rating current 50°C according to IEC 60947-280 A
Rating current 45°C according to IEC 60947-283.8 A
Rating current 40°C according to IEC 60947-287.5 A
Total power loss under IN4.8 W
Motor drive optionalNo
Rating current 25°C according to IEC 60947-297.7 A
Compatible with DIN rail mountingNo
Type of connectionwith screw
Standard textIEC 60947-2
European directive WEEEconcerned
Trip information on faultYes
Rated operational voltage Ue220 / 240 V
Rated insulation voltage690 V
Rated impulse withstand voltage8000 V
Product categories described in the W3E directive 2012/19/EUCategory 5
Integrated earth fault protectionNo
Complete device with protection unitNo
Motor drive integratedNo
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
UnitPCE
Sales status3C
EAN3250613135911
See more features
Documentations
Instruction manuals for HDA078Z 3243 kbpdfDownload
