Moulded Case Circuit Breaker h3 x160 TM FIX 1P1D 16A 18kA CTC

HDA014E

  • Higher Power & Switching

Moulded Case Circuit Breaker h3 x160 TM FIX 1P1D 16A 18kA CTC HDA014E

EAN-Nr.
3250613164508
Packaging
1 piece
Price
£185.76
/ piece *
£185.76
/ piece *

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in
  • Accessories
  • Technical characteristics
  • Environmental value
  • Documentations
  • More products
Download the sheet

Complete your system

Optional accessories

  • Terminal cover 1 products available

Complete your system

  • Terminal cover
  • HYA029H

    Terminal cover x160 1P long
    £23.15  / piece*
    Add to a list
    Add to a list

Technical characteristics

Elec­tric current
  • Rated current
    16 A
  • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 240 V AC IEC 60947-2
    18 kA
  • Rated service breaking capa­city Ics under 230 V AC according to IEC 60947-2
    18 kA
  • Rated current 10°C according to IEC 60947
    22 A
  • Rated current 15°C according to IEC 60947
    21.30 A
  • Rated current 20°C according to IEC 60947
    20.60 A
  • Rated current 25°C according to IEC 60947
    19.90 A
  • Rated current 30°C according to IEC 60947
    19.20 A
  • Rated current at 35°C according to IEC 60947
    18.40 A
  • Rated current at 40°C according to IEC 60947
    17.60 A
  • Rated current 45°C according to IEC 60947
    16.80 A
  • Rated current 50°C according to IEC 60947
    16 A
  • Rated current 55°C according to IEC 60947
    15 A
  • Rated current at 60°C according to IEC 60947
    14.10 A
  • Rated current 65°C according to IEC 60947
    13 A
  • Rated current 70°C according to IEC 60947
    11.90 A
Archi­tec­ture
  • Number of poles
    1
  • Control/­op­er­a­tion element
    Toggle
  • Device construc­tion type
    Fixed built-in
  • Neutral posi­tion
    Without neutral
Frequency
  • Frequency
    50 - 60 Hz
Voltage
  • Rated impulse with­stand voltage Uimp
    8,000 V
  • Rated insu­la­tion voltage Ui
    690 V
Func­tions
  • Trip unit
    TM F/F
Power
  • Total power loss under IN
    1.89 W
Endur­ance
  • Elec­tric endur­ance in number of cycles
    1,000
  • Number of mech­an­ical oper­a­tions
    4,000
Safety
  • Ingress Protec­tion (IP) class
    IP4X
Connec­tion
  • Cross-sec­tion flex­ible conductor
    6 - 70 mm²
  • Cross-sec­tion rigid conductor
    6 - 95 mm²
Install­a­tion, mounting
  • Nominal tight­ening torque
    6 - 6 Nm
  • Mount­ing-/­Con­nec­tion Posi­tion
    Front
Connectivity
  • Type of connec­tion
    Screw terminal
Settings
  • Thermal protec­tion knob setting xIN
    1, 1
  • Adjust­ment range short-term delayed short-­cir­cuit release
    0 - 0 A
Cable
  • Cable material
    Copper
Dimen­sions
  • Height
    130 mm
  • Width
    25 mm
  • Depth
    68 mm
Compat­ib­ility
  • Suit­able for DIN Rail
    No
Main elec­trical attrib­utes
  • Nominal tight­ening torque down terminal
    6 - 6 Nm
  • Nominal tight­ening torque top terminal
    6 - 6 Nm

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes
REACH conform Yes

Certifications and documents

REACH declaration HDA014E (english)
PDF
103,10 kB
RoHS declaration HDA014E (english)
PDF
103,59 kB

Downloads

  • Product image

    Image HDA014E | Hager

    Product Image HDA014E

  • Installation manual

    Image Installation manual International 2021-06-07 | Hager

    Installation manual International 2021-06-07

    PDF
    8,51 MB

  • Declaration of conformity

    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2022-02-17

    PDF
    276,25 kB
    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2022-02-16

    PDF
    215,43 kB
    Image EU Declaration of Conformity | Hager

    EU Declaration of Conformity

    Declaration of conformity en-GB 2025-03-20

    PDF
    430,96 kB
    Image UKCA Declaration of Conformity | Hager

    UKCA Declaration of Conformity

    Declaration of conformity en-GB 2025-03-20

    PDF
    435,49 kB
More documentation
