Movement detector 360° flush mounted with normally open contact EE805A
EAN-Nr.
3250612258758
Packaging
1 piece
Price
£114.26
/ piece
*
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Functions
-
Functioncan only be used as individual unit
Main electrical features
-
Rated operational voltage Ue230 V
-
Frequency50/60 Hz
Dimensions
-
Height of installed product15.5 mm
-
Width of installed product19 mm
Power
-
Halogen switching capacity 230V0 / 2300 W
-
Max. power with fluo uncompensated lamps1000 VA
-
Incandescent bulb power0 / 2300 W
Power supply
-
Supply voltage230 V +10% / -15%
Materials
-
Colourwhite
Lighting control
-
Brightness measurement range5 / 1000 Lux
Installation, mounting
-
Mounting typeflush-mounted
-
Maximum Mounting Height4 m
Connection
-
Type of contactsNormally open contact (NO)
-
Type of connectionwith plug-in terminals
Settings
-
Settingwith potentiometers for setting the response brightness and delay time
Scope of delivery
-
Componentwith fitting material
Safety
-
Protection classisol.class II
Use conditions
-
Operating temperature-5…45 °C
Downloads
-
Product image
-
Instruction manual
Instruction manuals for EE805A
Manual for EE804A-EE805A Presence and motion detector (en, 2017-09)
PDF936 KB -
User brochure
Service brochure
PDF12 MB -
Declaration of conformity
EU Declaration of conformity for EE805A
Declaration
PDF126 KB -
PEP document
Product environmental profile for EE805A
PDF439 KB -
RoHS report
Pollutant guidelines for EE805A
RoHS declaration EE805A (english)
PDF103 KB
