Current Transformer with RJ45 output BGUK 3-Phase 250A/330mV Class 1 pitch 35mm EC25250CT
Price
£85.32
/ piece
*
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
Technical characteristics
Specific identificaton attributes for Protection
-
Filter Type product3-phase current transformer replacement
Functions
-
Accuracy class1
Dimensions
-
Height80 mm
-
Width105 mm
-
Depth54 mm
-
Height of opening25 mm
-
Width of opening21 mm
Connectivity
-
Type of connectionPlug-in connection
Frequency
-
Frequency47 - 63 Hz
Voltage
-
Rated power-frequency withstand voltage (r.m.s.)3,000 V
-
Max. operating voltage720 V
Use conditions
-
Operating temperature-25 - 50 °C
-
Storage/transport temperature-40 - 85 °C
Safety
-
Ingress Protection (IP) classIP20
Electric current
-
Rated primary current (Ipr)250 A
-
Rated continuous thermal current1,2*In
-
Rated short-time thermal current (Ith/1s)60*Ipr
-
Rated dynamic current2.5*Ith
-
Over voltage limiting factorFS 5
Installation, mounting
-
Mounting onDIN rail, Busbar, Cable
Architecture
-
Number of poles3
catalog.pageproduct.title_sustainability.h2
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
catalog.pageproduct.sustainability_block.downloads_h3
Downloads
-
Product image
-
GeneratedProductDatasheet
Hager Product data sheet EC25250CT
