BD163T

Earth leakage add-on-block 3P 63A 30mA A Class 1mod Electronic
EAN
3250611344872
Quantity
1
Trade price*
£396.19 /prt.*
  • Architecture
    • Neutral position
      • right
    • Number of poles
      • 3 P
  • Main electrical features
    • Rated operational voltage Ue
      • 240 / 415 V
    • Frequency
      • 50 Hz
    • Rated current
      • 63 A
  • Voltage
    • Rated insulation voltage
      • 500 V
    • Rated impulse withstand voltage
      • 4000 V
  • Electric current
    • Rated residual operating current
      • 30 mA
  • Power
    • Total power loss under IN
      • 3.2 W
  • Endurance
    • Electric endurance in number of cycles
      • 1000
    • Number of mechanical operations
      • 1000
  • Capacity
    • Number of modules
      • 1
  • Installation, mounting
    • Tightening torque
      • 3,5Nm
  • Connection
    • Connection cross-sect. flexible conductor
      • 16mm²
    • Connection cross-sect. rigid cable
      • 25mm²
  • Standards
    • European directive WEEE
      • concerned
  • Safety
    • Protection index IP
      • IP20
    • Residual current type
      • A
  • Use conditions
    • Operating temperature
      • -5…40 °C
