| Symbols for applications | LOOP-TERMINAL__APP-SYMBOL.EPS |
|---|---|
| Color_Label | white |
| Colour of design line | white |
| Colour independent of design lines | white |
| Design lines special colours | white |
| Conductor cross-section | 2 x 4 mm² |
| Depth | 24 mm |
| Height | 86 mm |
| Insertion depth | 10.8 mm |
| Colour | white |
| Material | Steel |
| Standard | BS EN 60669-1 |
| Rated current | 10 AX |
| Appliance switch type | No |
| Component | with 2 fixing screws M3.5 x 20 mm and M3.5 x 30 mm each |
| Imprint | with clear terminal markings |
| Installation mode | for flush-mounted and hollow-wall mounting |
| Labelling | without labelling |
| Lighting | with control LED for ON |
| Push-buttons | No |
| Switch mode | 2 way |
| Terminal | unique patented loop terminal allows neutral looping at the switch |
| Width | 86 mm |
| Unit | PCE |
| EAN | 3250617261784 |
| Sales status | 3C |
