- Architecture
- Fixing mode
- DIN rail type O (symmetrical)
-
- Main electrical features
- Rated operational voltage Ue
- 230 V
- Rated current
- 0.03 A
- Type of supply voltage
- AC
-
- Dimensions
- Depth of installed product
- 65 mm
- Height of installed product
- 80 mm
- Width of installed product
- 18 mm
-
- Power
- Power consumed
- 6.5 VA
- Total power loss under IN
- 6.5 W
-
- Capacity
- Number of modules
- 1
-
- Materials
- RAL colour number
- 7032
- Material
- polyamide
-
- Connection
- Connection cross-sect. flexible conductor
- 4mm²
- Connection cross-sect. rigid cable
- 6mm²
-
- Standards
- European directive WEEE
- concerned
-
- Safety
- Protection index IP
- IP20
-
- Use conditions
- Operating temperature
- -10…40 °C
-
