FWB encl.,univers,7rows 336mod cl.II IP44,plain door,1100x1050x161mm,brass term. FWB74

EAN-Nr.
3250612737574
Packaging
1 Prt.
Price
£896.74
/ piece *

Technical characteristics

Architecture
  • Fixing mode
    surface-mounting
Dimensions
  • Depth of installed product
    165 mm
  • Height of installed product
    1100 mm
  • Width of installed product
    1050 mm
Cover, door
  • Door locking
    without
Materials
  • Colour
    white
  • Colour
    white
  • RAL colour
    RAL 9010 - Pure white
  • Material
    sheet steel
Equipment
  • Number of rows
    28
  • Quantity of section in width
    4
  • Can be accessorized
    Yes
Standards
  • European directive WEEE
    concerned
Safety
  • Protection index IP
    IP44
  • Protection class
    isol.class II

Downloads

  • Product image

    Image FWB74  | Hager

    Product Image FWB74

  • Product notice

    Image Instruction manuals for FWB74  | Hager

    Instruction manuals for FWB74

    Schrank ohne QuickSet-Rahmen - IP44 & IP54 -- SKII

    PDF
    1 MB
  • Installation guide

    Image Installation manuals for FWB74  | Hager

    Installation manuals for FWB74

    PDF
    3 MB
  • BIM models

    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range Univers enclosures for UK (Lang. : en) IP44 with installation System hosted-V2021

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range : Univers. Recessed mounted switchboard IP44 with DIN rail system. English - Non hosted family - REVIT Family 2020 - V2022

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range Univers enclosures for UK (Lang. : en) IP44 with installation System surface mounted hosted-V2021

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range Univers enclosures for UK (Lang. : en) IP44 with installation System surface mounted no hosted-V2021

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range Univers enclosures for UK (Lang. : en) IP44 with installation System no hosted-V2021

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range : Univers. Surface mounted switchboard IP44 with DIN rail system. English - Non hosted family - REVIT Family 2020 - V2022

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range : Univers. Recessed mounted switchboard IP44 with DIN rail system. English - Hosted family - REVIT Family 2020 - V2022

    RFA
    1 MB
    Image BIM models for FWB74  | Hager

    BIM models for FWB74

    Range : Univers. Surface mounted switchboard IP44 with DIN rail system. English - Hosted family - REVIT Family 2020 - V2022

    RFA
    1 MB
  • Product manuals

    Image Manuals for FWB74  | Hager

    Manuals for FWB74

    PDF
    23 MB
  • Product declaration

    Image EU Declaration of conformity for FWB74  | Hager

    EU Declaration of conformity for FWB74

    Declaration

    PDF
    143 KB
    Image EU Declaration of conformity for FWB74  | Hager

    EU Declaration of conformity for FWB74

    Declaration

    PDF
    332 KB
  • Product ROHS

    Image RoHS certificate for FWB74  | Hager

    RoHS certificate for FWB74

    PDF
    33 KB
    Image RoHS certificate for FWB74  | Hager

    RoHS certificate for FWB74

    PDF
    33 KB
More documentation
