    • Home
    • Catalogue
    • EV102
    EAN-Nr.
    3250612421022
    Packaging
    1 piece

    Universal remote control dimmer 1000W + display EV102

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in
    Phase out product: please contact your electrical wholesaler for availability

    Follow-up products :

    EVN004

    Universal remote control dimmer 1000W + display

    EV102

    • Technical characteristics
    • Documentations
    Download the sheet

    Technical characteristics

    Voltage
    • Rated oper­a­tional voltage Ue
      230 - 230 V
    Frequency
    • Frequency
      50 - 50 Hz
    Mater­ials
    • Colour
      Grey
    • RAL code
      7035
    Dimen­sions
    • Height
      85 mm
    • Width
      88.50 mm
    • Depth
      65 mm
    Power
    • Power consump­tion during oper­a­tion
      15 VA
    • Power consump­tion standby
      3 W
    • Power incan­des­cent lamp
      20 - 1,000 W
    Use condi­tions
    • Oper­ating temper­ature
      -10 - 45 °C
    Connec­tion
    • Cross-sec­tion rigid conductor
      1.5 - 10 mm²
    • Cross-sec­tion flex­ible conductor
      1 - 16 mm²
    Capa­city
    • Number of modules
      5
    Texts
    • Dimming prin­ciple
      Auto­matic load detec­tion
    • Install­a­tion mode
      For mounting on DIN rail
    • Type of connec­tion
      With screw terminals
    • Junc­tion
      Connec­tion for illu­min­ated (max. 5 mA) or standard push-but­tons
    Equip­ment
    • Substa­tion input
      Yes

    Downloads

    • Product image

      Image EV102 | Hager

      Product Image EV102

    • Product datasheet

      Image Hager Product data sheet EV102 | Hager

      Hager Product data sheet EV102

      Universal remote control dimmer 1000W + display

      PDF

    • Installation manual

      Image Annexe de parametrage pour televariateurs EV 102 et EV 108 | Hager

      Annexe de parametrage pour televariateurs EV 102 et EV 108

      Installation manual en-GB, es-ES, fr-FR, de-DE, nl-NL, nn-NO, pt-PT, sv-SE 2020-01-01

      PDF
      2,40 MB
      Image Installation manual en-GB, fr-FR, de-DE, nl-NL 2017-09-11 | Hager

      Installation manual en-GB, fr-FR, de-DE, nl-NL 2017-09-11

      PDF
      1,59 MB

    • Declaration of conformity

      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2020-02-07

      PDF
      108,61 kB
