The Hager MCB 2P 25kA B-6A 2M safeguards circuits from overloads and short circuits with 2‑pole isolation up to 415 V AC. Its B‑curve 6 A suits resistive/lighting loads, while high breaking capacities (Icu 50 kA @230 V, 25 kA @400 V; Ics 15 kA) enhance safety for demanding installations. Compact 2 modules, IP20, 6 kV impulse withstand, 50-60 Hz, 360° mounting, biconnect/screw terminals for 1-35 mm²; 4,000 electrical/20,000 mechanical ops.

EAN

3250614645587

Packaging

1 Piece

MCB 2P 10A Curve B 25kA Icu 2 Modules 415V AC NQN206

Phase out product: please contact your electrical wholesaler for availability

Accessories
Technical properties
Documentations

Complete your system

Modular phase busbar 1 products available
Terminal cover 1 products available
AOB type A-HI 3 products available
AOB type AC 5 products available
Protective cap/strip for phase busbar 1 products available

Technical properties

Rated current IN

6 A
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-2

7.50 kA
Rated ultimate short-circuit breaking capacity Icu AC IEC 60947-2

25 kA
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-2

25 kA
Rated current at -15°C

7.27 A
Rated current at -10°C

7.13 A
Rated current at -5°C

6.99 A
Rated current at 0°C

6.85 A
Rated current at 5°C

6.71 A
Rated current at 10°C

6.57 A
Rated current at 15°C

6.42 A
Rated current at 20°C

6.28 A
Rated current at 25°C

6.14 A
Rated current at 30°C

6 A
Rated current at 35°C

5.84 A
Rated current at 40°C

5.68 A
Rated current at 45°C

5.51 A
Rated current at 50°C

5.35 A
Rated current at 55°C

5.19 A
Rated current at 60°C

5.03 A
Rated current at 65°C

4.86 A
Rated current at 70°C

4.7 A
Rated ultimate short-circuit breaking capacity Icu under 230 V AC IEC 60947-2

50 kA

Type of pole

2P
Curve

B

Number of modules

2

Nominal tightening torque top terminal

2.80 - 2.80 Nm
Nominal tightening torque down terminal

2.80 - 2.80 Nm
Nominal tightening torque

2.80 - 2.80 Nm
Type of bottom connection for modular devices

biconnect
Type of top connection for modular devices

Screw terminal

Rated operational voltage Ue

230 - 415 V
Type voltage supply

AC
Rated insulation voltage Ui

500 V
Rated impulse withstand voltage Uimp

6000 V

Frequency

50 - 60 Hz

Cross-section of input and output with screws, for massive conductors

1 - 35 mm²
Cross-section of input and output with screws, for flexible conductors

1 - 25 mm²
Cross-section of input with screws, for flexible conductors

1 - 25 mm²
Cross-section of input with screws, for massive conductors

1 - 35 mm²
