Earth leakage add-on block 4P 63A 100mA AC S Class BN464
EAN
3250611444640
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Compatible products
-
Referenced by 130 products available
Referenced by
-
NCN432AMCB 4P 10kA/15kA C-32A 4M
-
NBN440AMCB 4P 10kA/15kA B-40A 4M
-
NFN425MCB 4P 6/10kA C-25A 4M
-
NDN450AMCB 4P 10kA/15kA D-50A 4M
-
NDN432AMCB 4P 10kA/15kA D-32A 4M
-
NCN406AMCB 4P 10kA/15kA C-6A 4M
-
NCN404AMCB 4P 10kA/15kA C-4A 4M
-
NCN402AMCB 4P 10kA/15kA C-2A 4M
-
NBN450AMCB 4P 10kA/15kA B-50A 4M
-
NBN410AMCB 4P 10kA/15kA B-10A 4M
-
NBN406AMCB 4P 10kA/15kA B-6A 4M
-
NFN432MCB 4P 6/10kA C-32A 4M
-
NGN416MCB 4P 6/10kA D-16A 4M
-
NFN463MCB 4P 6/10kA C-63A 4M
-
NDN416AMCB 4P 10kA/15kA D-16A 4M
-
NDN463AMCB 4P 10kA/15kA D-63A 4M
-
NBN416AMCB 4P 10kA/15kA B-16A 4M
-
NFN402MCB 4P 6/10kA C-2A 4M
-
NEN432MCB 4P 6/10kA B-32A 4M
-
NBN420AMCB 4P 10kA/15kA B-20A 4M
Technical properties
Voltage
-
Rated operational voltage Ue230 - 400 V
-
Rated insulation voltage Ui500 V
-
Rated impulse withstand voltage Uimp4000 V
Frequency
-
Frequency50 - 50 Hz
Electric current
-
Rated residual operating current Idn100 mA
-
Rated current63 A
Architecture
-
Number of poles4
-
Neutral positionLeft
Connectivity
-
Down connection alignment for modular devicesAligned terminal
Dimensions
-
Height70 mm
-
Width35 mm
-
Depth92 mm
