RCBO 4P 10kA C-32A 30mA A ADX432T
EAN-Nr.
3250611033134
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Locking interlocking functions 1 products available -
Under voltage coil 1 products available -
Shunt release 2 products available -
Undervoltage and overvoltage release 1 products available -
Auxiliaries contact block 2 products available -
Modular phase busbar 1 products available
Complete your system
Technical characteristics
Electric current
-
Rated current32 A
-
Rated residual operating current Idn30 mA
-
Rated current -25°C39.90 A
-
Rated current at -20°C39.30 A
-
Rated current -15°C38.60 A
-
Rated current -10°C37.90 A
-
Rated current -5°C37.20 A
-
Rated current at 0°C36.50 A
-
Rated current 5°C35.80 A
-
Rated current 10°C35.10 A
-
Rated current 15°C34.30 A
-
Rated current at 20°C33.60 A
-
Rated current 25°C32.80 A
-
Rated current 30°C32 A
-
Rated current 35°C31.20 A
-
Rated current at 40°C30.30 A
-
Rated current at 45°C29.40 A
-
Rated current at 50°C28.50 A
-
Rated current 55°C27.50 A
-
Rated current 60°C26.50 A
-
Rated service breaking capacity Ics AC according to IEC 60898-17.50 kA
Architecture
-
CurveC
-
Neutral positionRight
-
Type of pole4P
-
Number of protected poles4
Capacity
-
Number of modules4
Safety
-
Residual current typeA
-
Ingress Protection (IP) classIP2X
Voltage
-
Type voltage supplyAC
-
Rated operational voltage Ue230 - 415 V
-
Rated insulation voltage Ui500 V
-
Dielectric strength value of power frequency2 kV
-
Rated impulse withstand voltage Uimp4,000 V
Installation, mounting
-
Nominal tightening torque down terminal2 - 2 Nm
-
Nominal tightening torque top terminal2 - 2 Nm
-
Nominal tightening torque2 - 2 Nm
-
360° mounting position possibleYes
-
Type of top connection for modular devicesScrew terminal
-
Type of bottom connection for modular devicesbiconnect, Bypass
Main electrical attributes
-
Rated short-circuit breaking capacity Icn AC according to IEC 60898-110 kA
Frequency
-
Frequency50 - 50 Hz
Connection
-
Cross-section of input with screws, for flexible conductors1 - 16 mm²
-
Cross-section of input with screws, for massive conductors1 - 25 mm²
Use conditions
-
Class of energy limitation I²t3
-
Degree of pollution according to IEC 60664 / IEC 60947-22
-
Operating temperature-25 - 40 °C
Dimensions
-
Height84 mm
-
Width71 mm
-
Depth70 mm
Power
-
Total power loss under IN14.60 W
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet ADX432T
