The Hager MCB 2P 20kA B-40A 2M miniature circuit breaker protects circuits against overloads and short circuits. Rated 40A, B-curve, 2 poles, it delivers high breaking capacity: Icu 40kA at 230V, 20kA at 400V (Ics 15kA), Icn 10kA IEC 60898-1. For 415V AC, 50/60Hz. Compact 2 modules (35 mm), IP20, 6kV impulse, -25…70°C. Screw/biconnect terminals for 1-35 mm². Ideal for residential and commercial panels.
EAN
3250614645655
VPE
1 piece
Miniature circuit breaker 3P 2A 6/10kA Curve C 400V AC 3 Modules NQN240
Phase out product: please contact your electrical wholesaler for availability
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
product.page.accessories.title
product.page.accessories.associated-products
-
Modular phase busbar 1 product.page.accessories.products-available -
Terminal cover 1 product.page.accessories.products-available -
AOB type AC 4 product.page.accessories.products-available -
AOB type A-HI 1 product.page.accessories.products-available -
Protective cap/strip for phase busbar 1 product.page.accessories.products-available
product.page.accessories.title-modal
Technical characteristics
Electric current
-
Rated current IN40 A
-
Rated service breaking capacity Ics under 230 V AC according to IEC 60947-215 kA
-
Rated ultimate short-circuit breaking capacity Icu AC IEC 60947-220 kA
-
Rated ultimate short-circuit breaking capacity Icu under 400 V AC IEC 60947-220 kA
-
Rated current at -15°C57.27 A
-
Rated current at -10°C55.35 A
-
Rated current at -5°C53.43 A
-
Rated current at 0°C51.51 A
-
Rated current at 5°C49.59 A
-
Rated current at 10°C47.68 A
-
Rated current at 15°C45.76 A
-
Rated current at 20°C43.84 A
-
Rated current at 25°C41.92 A
-
Rated current at 30°C40 A
-
Rated current at 35°C38.75 A
-
Rated current at 40°C37.5 A
-
Rated current at 45°C36.24 A
-
Rated current at 50°C34.99 A
-
Rated current at 55°C33.74 A
-
Rated current at 60°C32.49 A
-
Rated current at 65°C31.23 A
-
Rated current at 70°C29.98 A
-
Rated ultimate short-circuit breaking capacity Icu under 230 V AC IEC 60947-240 kA
Architecture
-
Type of pole2P
-
CurveB
Capacity
-
Number of modules2
Installation, mounting
-
Nominal tightening torque top terminal2.80 - 2.80 Nm
-
Nominal tightening torque down terminal2.80 - 2.80 Nm
-
Nominal tightening torque2.80 - 2.80 Nm
-
Type of bottom connection for modular devicesbiconnect
-
Type of top connection for modular devicesScrew terminal
-
360° mounting position possibleYes
Voltage
-
Rated operational voltage Ue230 - 415 V
-
Type voltage supplyAC
-
Rated insulation voltage Ui500 V
-
Rated impulse withstand voltage Uimp6000 V
Frequency
-
Frequency50 - 60 Hz
Connection
-
Cross-section of input and output with screws, for massive conductors1 - 35 mm²
-
Cross-section of input and output with screws, for flexible conductors1 - 25 mm²
-
Cross-section of input with screws, for flexible conductors1 - 25 mm²
-
Cross-section of input with screws, for massive conductors1 - 35 mm²
Safety
-
Ingress Protection (IP) classIP20
Use conditions
-
Degree of pollution according to IEC 60664 / IEC 60947-22
-
Class of energy limitation I²t3
-
Air humidity protectionFor all climates
-
Operating temperature-25 - 70 °C
Power
-
Power dissipation at IN6.70 W
Connectivity
-
Type of connectionScrew terminal
-
Top connection alignment for modular devicesAligned terminal
-
Down connection alignment for modular devicesAligned terminal
Dimensions
-
Height83 mm
-
Width35 mm
-
Depth70 mm
Endurance
-
Electric endurance in number of cycles4000
