The Hager LFS steel trunking 60x200 mm in traffic white (RAL9016) routes and protects cables in commercial or office installs. Robust varnished steel with IK08 and IP30 ensures durable, clean runs. 2 m lengths provide 9,770 mm² capacity, holding up to 41 Ø11 mm cables. Configurable 1-4 compartments with up to 3 pluggable partitions and an included cable retaining clip; couplers sold separately.
EAN
4012740994514
Packaging
4 Meters
T-piece Overlapping Steel LFS 60x150 Trunking Traffic White IK08 IP30 LFS6020009016
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Cable clip/retainer for installation duct 2 products available -
Earthing set 1 products available -
Coupler for installation duct 1 products available -
Partition for wall duct 2 products available -
End piece for installation duct 1 products available -
Internal corner for installation duct 1 products available
Complete your system
Technical properties
Dimensions
-
Height60 mm
-
Width200 mm
-
Length2000 mm
-
Inner cross-section9770 - 9770 mm²
Cover, door
-
Type of lidLoose
Capacity
-
Max. number of cables (Ø11mm, 50% filled, without devices)41
Materials
-
MaterialSteel
-
TreatmentVarnished
-
RAL code9016
-
ColourTraffic white
-
TransparentNo
Safety
-
Impact resistance IKIK08
-
Ingress Protection (IP) classIP30
Standards
-
Suitable for functional integrity according to DIN4102-12No
Use conditions
-
Operating temperature-5 - 90 °C
Connectivity
-
Trunking couplingCouplers as separate reference
Equipment
-
Number of partitions0
-
Number of compartments1 - 4
-
Number of pluggable partitions3
-
Cable retaining clip includedYes
-
Number of cable retainers per meter2
-
With protective filmNo
Configuration
-
With antibacterial treatmentNo
Scope of delivery
-
Delivery on rollNo
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
More documentation
Discover more of this product range
-
5
-
1
LFS602003VERZexternal corner overlapping steel/plaster for LFS 60x200mm galvanized -
2
LFS602005VERZflat angle overlapping steel/plaster for LFS trunking 60x200mm galvanized -
3
LFS602004VERZinternal corner overlapping steel/plaster for LFS 60x200mm galvanized -
4
LFS602006VERZendcap steel/plaster for LFS trunking 60x200mm galvanized -
5
LFS601508VERZT-piece overlapping steel/plaster for LFS trunking 60x150mm galvanized
