The Hager external overlapping corner for LFS 60x200 trunking provides a neat, robust 90° outside bend. Varnished steel in traffic white (RAL9016) ensures durability and a clean finish. With IK08 impact resistance and IP30 protection, it safeguards cabling. Dimensions 60×200 mm (measurement a: 50 mm). Moulded for quick, seamless installation. Operating range -5 to 90°C. Ideal for residential and commercial cable routing.
EAN
4012740007627
Packaging
4
LFS Endcap 60x200 Steel Traffic White RAL9016 IK08 IP30 Snap-on/Screw LFS6020039016
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Dimensions
-
Height60 mm
-
Width200 mm
-
Measurement a50 mm
Accessories
-
Type of accessoryMoulded
Settings
-
Angle range90 - 90
Materials
-
MaterialSteel
-
TreatmentVarnished
-
ColourTraffic white
-
RAL code9016
Safety
-
Impact resistance IKIK08
-
Ingress Protection (IP) classIP30
Standards
-
Suitable for functional integrity according to DIN4102-12No
Use conditions
-
Operating temperature-5 - 90 °C
Equipment
-
With protective filmNo
Configuration
-
OverlappingYes
-
Related SeriesLFS 60x200
Environmental value
