The Hager insulated busbar 3P+N 80A prong 16mm² (57 modules) distributes power safely across three phases plus neutral. Rated 80 A at 230-400 V with 4 kV impulse withstand, it suits residential and commercial boards. The 1000 mm pin-type phase busbar accepts 16 mm² rigid conductors and enables quick, tidy linking of up to 57 modules, improving reliability, saving time, and optimizing panel space.
EAN
3250613720179
Packaging
10
Load break switch 4P 400A Visible breaking Main switch Long rotary handle KB480B
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Protective cap/strip for phase busbar 1 products available
Technical properties
Electric current
-
Rated current80 A
Architecture
-
Number of poles4
Dimensions
-
Length1000 mm
Voltage
-
Rated impulse withstand voltage Uimp4000 V
-
Rated operational voltage Ue230 - 400 V
Connection
-
Cross-section rigid conductor16 mm²
-
Connector/plug typePhase busbar with pin
Capacity
-
Number of modules57
