The Hager insulated busbar for 4 motor starters (3P, 63A) streamlines three-phase distribution and parallel feeding of starters. Fork-type phase busbar accepts 10 mm² rigid conductors for fast, secure connections. Rated 230-400 V with 4.5 kV impulse withstand, 176 mm (10 modules) for compact panels. Operates -25 to 55 °C, improving safety, reducing wiring time, and ensuring reliable motor control.
EAN
3250613740443
Packaging
10
Ceiling Mounting Bracket for EE820 Motion Detector, White KD304M
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Electric current
-
Rated current63 A
Architecture
-
Number of poles3
Dimensions
-
Length176 mm
Voltage
-
Rated impulse withstand voltage Uimp4500 V
-
Rated operational voltage Ue230 - 400 V
Connection
-
Cross-section rigid conductor10 mm²
-
Connector/plug typePhase busbar with fork
Use conditions
-
Operating temperature-25 - 55 °C
Capacity
-
Number of modules10
