The Hager insulated busbar for 3 motor starters (3P, 63 A) enables fast, safe interconnection of starters on 230-400 V systems. Fork phase busbar for 10 mm² rigid conductors, 132 mm length (7.5 modules), with 4.5 kV impulse withstand. Insulated design enhances safety, cuts wiring time and panel space, and operates reliably from -25 to +55 °C.
EAN
3250613740436
Packaging
10
Insulated phase busbar 3P 63A fork 10mm² for 4 motor starters KD303M
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Electric current
-
Rated current IN63 A
Architecture
-
Number of poles3
Dimensions
-
Length132 mm
Voltage
-
Rated impulse withstand voltage Uimp4500 V
-
Rated operational voltage Ue230 - 400 V
Connection
-
Cross-section rigid conductor10 mm²
-
Connector/plug typePhase busbar with fork
Use conditions
-
Operating temperature-25 - 55 °C
Capacity
-
Number of modules7.50
