The Hager insulated 3‑pole pin busbar 80A (12 modules) streamlines phase distribution across MCBs. Rated 230-400 V with 4 kV impulse withstand, it delivers reliable, safe connections. Its insulated, 210 mm format keeps panels compact and tidy, cutting wiring time and errors. Suited to pin (prong) devices, it accepts rigid conductors up to 16 mm² for robust, efficient assembly in residential and commercial boards.
EAN
3250613720216
Packaging
25
RCCB 3P+N 40A 30mA Type A HI 6kA 230-400V 4 Modules KB380A
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Electric current
-
Rated current IN80 A
Architecture
-
Number of poles3
Dimensions
-
Length210 mm
Voltage
-
Rated impulse withstand voltage Uimp4000 V
-
Rated operational voltage Ue230 - 400 V
Connection
-
Cross-section rigid conductor16 mm²
-
Connector/plug typePhase busbar with pin
Capacity
-
Number of modules12
