The Hager insulated 3P 80A prong busbar (16 mm², 57 modules, 1000 mm) streamlines three-phase distribution in panels. Rated 230-400 V with 4 kV impulse withstand, it delivers safe, reliable connections. The pin-type phase busbar suits rigid 16 mm² conductors, enabling fast, tidy feeding of device rows while saving space and reducing wiring errors in residential and commercial boards.
EAN
3250613720131
Packaging
10
Insulated phase busbar 3P+N 63A pin 10mm² 24 modules 230-400V KB380B
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Electric current
-
Rated current80 A
Architecture
-
Number of poles3
-
Type of pole3P
Dimensions
-
Length1000 mm
Voltage
-
Rated impulse withstand voltage Uimp4000 V
-
Rated operational voltage Ue230 - 400 V
Connection
-
Cross-section rigid conductor16 mm²
-
Connector/plug typePhase busbar with pin
Capacity
-
Number of modules57
Environmental value
